Vacuum Thermoforming Packaging Machine
- 5 Set / Sets per Month
- NINGBO PORT
- T/T Credit Card
You May Like
-
Automatic Thermoforming and Vacuum Strech Packaging Machinery
-
Chicken (Whole and in Pieces) Tray Packaging in Stretch Film
-
Bacon Skin Packaging in Thermoforming in Rigid Film
-
Ham Packaging in Thermoforming in Vacuum Pack in Flexible Film
-
BD-320E/420E/520E Automatic Thermoformer Vacuum Cheese Packaging Machine
-
Pizza Packaging in Flow Pack Wrapper with Barrier Shrink Film and MAP
Product Details
| Condition | New | Application | Chemical, Commodity, Food, Medical | |
| Packaging Type | Bags, Film, Other, Bags, Film, Rigid or flexible tray | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 380V/50HZ | Power | 15KW | |
| Place of Origin | Zhejiang, China | Brand Name | APT | |
| Model Number | BD-520B | Dimension(L*W*H) | 6200 X 1400 X 1900mm | |
| Weight | 2100kg | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Usage:
BD-320B/420B/520B automatic stretch vacuum packaging is a thermoforming machine designed to pack medical products, such as needles, syringes, infusion tubes, catheters, medical dressing products. The top film is paper and the bottom film is flexible film.
Model | BD-320B | BD-420B | BD-520B |
Upper Film Width | 292mm | 392mm | 492mm |
Lower Film Width | 322mm | 422mm | 522mm |
Upper Film Thickness | 0.05-0.7mm | 0.05-0.7mm | 0.05-0.7mm |
Lower PE Film Thickness | 0.05-0.5mm | 0.05-0.5mm | 0.05-0.5mm |
Running Speed | 1-8cycles/min | 1-8cycles/min | 1-8cycles/min |
Max. Packing Size |
| 400x400x60mm | 495x500x60mm |
The Power of Heater |
| 13KW | 13KW |
Power Consumption |
| 15KW | 15KW |
Power Voltage | 380V/50HZ | 380V/50HZ | 380V/50HZ |
Approx. Machine Weight | 1300kg | 1700kg | 2100kg |
Approx. Machine Dimension | 5100x900x1800mm | 6150×1200×1900mm | 6200X1400x1900mm |
No. | Item | Brand |
1 | PLC | Mitsubishi, Japan |
2 | Expansion Module | |
3 | Touch Screen | Weinview, Taiwan |
4 | Chain Drive Servomotor | Mitsubishi, Japan (1KW) |
5 | Vacuum Pump | Bush, Germany |
6 | Temperature Controller | Shanghai Yatai, China |
7 | Breaker | Schneider, France |
8 | Solenoid Valve | Airtac, Taiwan |
9 | Air Cylinder | Airtac, Taiwan |
10 | Solid State Relay | Langning, China |
11 | Mold Material | Aluminum |
12 | Machine Frame | 304 Stainless Steel |
1. All processing steps be done automatically , which saves labor and high efficiency .
2. This machine operation is convenient and stable performance .
3. One machine can make different products, just change the mould, It has multifunction .
4. Machine can be customized according to customer requirement .
Home Website: http://apt-group.en.china.cn/
Product Video Link:/watch?v=Cu9a7cBxLSg
Packing Machine
Loading Machine
Shipping Machine
Sales Market Distribution
- Installation Services are available with all customers.
- we can send our Enginner to your company to install the machines If customer needs.
- We can train your staffs how to run the machine efficiently and safely.
3. After Sales Service
- Guaranty: One Year and offer the lifetime maintenance service.
- During warranty period and after warranty period, We will come for regular checks on machine and make records to ensure the normal operation of equipment.
- Our experienced engineer are always available for dispatching abroad to help customers.
- Any question, welcome to contact us at any time.
Thanks a lot for viewing our product ! ^_^ If you are interested in our product and have any question, welcome to contact me any time !
Looking forward to your inquiry !Wish you a nice day!
