HD digital universal Multi Grade Dual Single LNB
- 500000 Piece / Pieces per Month
- shenzhen/zhuhai
- T/T Credit Card
You May Like
Product Details
| Brand Name | Gecen/OEM | Model Number | GKF-2201 | |
| Place of Origin | Guangdong, China |
Product Description
product name: Universal MULTI-GRADE DUAL SINGLE LNB
Model number: GKF-2201
Easy installation
Low noise figure
HD ready
Low power consumption
High quality weather protection
Simplest solution to achieve use one dish to receive two satellite
-
Item Specification Item Specification Input Frequency Range Vertical:12.25~12.75GHz Noise Figure 0.3dB(Typ.) Horizontal:12.25~12.75GHz Gain Flatness ±0.5dB/26MHz Output Frequency Range Vertical:950~1450MHz Band Stack Rejection 5dB(Min.) Horizontal:1500~2000MHz Cross POL. Isolation 25dB(Typ.) L.O. Frequency Vertical:11.3GHz Image Rejection 40dB(Min.) Horizontal:10.75GHz Output VSWR 2.0:1(Max.) L.O. Frequency Stability ±1.0MHz (Max.)@+25℃ P1dB 0dBm (Min.) ±2.0 MHz (Max.)@-30℃~+70℃ DC Current Consumption 110mA(Typ.) L.O. Phase Noise -60dBc/Hz@1KHz POL. Switching Voltage 10.0~20.0V -80dBc/Hz@10KHz Relative Humidity 0%~95% -100dBc/Hz@100KHz Operating Temperature -30℃~+70℃ Conversion Gain 60dB(Typ.) Connector Type 75Ω Female Connector
• Superior Phase Noise performance, DVB-S2 (HDTV) compliant
• Low Noise Figure
• Higher Conversion Gain
• Excellent Cross Polarization Isolation
• Ultimate Reliability
• High quality weather protection
OFFER [OEM box] [white box]
60 pcs/ctn
canton box size: 62*41.5*26 cm
1.Where has this product been sold?
Cover seven continents,224 countries in the world.
2. What certification does the products have?
CE,GMC
3.What kind of package can you offer?
OEM box with your brand, white box, gift box
