1.0ton Counter Balance Stacker Lifting 3000mm With CE
- shanghai
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Anhui, China | |
| Brand Name | MIMA | Model Number | TBB | |
| Dimension(L*W*H) | 2720*1010*1837 | Certification | CE | |
| Warranty | 12 months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
counter balance stacker,TBB seriesLoad capacity:1000kg;
lift hegith:3500mm;
with AC driving motor
1.0ton Counter Balance stacker lifting 3000mm with CE
TBB Electric pallet stacker , rated load capacity: 1000kg, lift height:3500mm, it's can used for double-face pallet' transportation;
1. .Speed Limited for high position,to aviod the possibility of products' overturning when high speed in high position;
2.Curve safe control,the forklift will reduce the speed automatic when turning, to aviod the ejection of operator and products from the vehicle by the high speed;
3.Regenerative braking function to reduce the operation cost;
4.Safe cutoff valve,to protect the operator and goods in well condition;
5.Shock Absorption of Pedal,to ensure the comfortable of working and reduce the fatigue;
6.Reinforced Mast,to ensure the mast are not out of shape and lift the goods smoothly;
7.Ergonomics multi-functional operation handle.
| TBB10 2-Stage mast | TBB10S 2-stage mast | ||||
| Standard | Power Type | Battery | Battery | |||
| Operate Type | Stand-on | Stand-on | ||||
| Rated Capacity | Q(kg) | 1000 | 1000 | |||
| Load center | C(mm) | 500 | 500 | |||
| T y r e | Wheel Type | Polyurethane Tyre | ||||
| Drive Wheel | Φ267×114 | Φ267×114 | ||||
| Drive Wheel | Φ215×75 | Φ215×75 | ||||
| Swivel caster | Φ150×50 | Φ150×50 | ||||
| Tyres No. -front/rear (X=drive wheel) | 2/1X=2 | 2/1X+2 | ||||
| D i m e n s i o n | Mast Tilt Angle----Upward/Downward--deg. | α/β(º) | / | 3/5 | ||
| Lift Height | h1(mm) | 2500 | 2500 | |||
| Height---Mast Lowered | h3(mm) | 1837 | 1837 | |||
| Height-Mast Extended | h4(mm) | 3068 | 3068 | |||
| Height-Mast Extended w/ Load-Backre | h5(mm) | 3355 | 3355 | |||
| Mast Min Ground Clearance | h7(mm) | 80 | 80 | |||
| Overall Length (Pedal extened /cloased) | 11(mm) | 3140/2720 | 3140/2720 | |||
| Length to fork face (pedal extended /closed) | 12(mm) | 2070/1650 | 2070/1650 | |||
| Front Overhang | x(mm) | 166 | 166 | |||
| Overall Width (Front /rear) | b1/b2(mm) | 1010/900 | 1010/900 | |||
| Fork Dimensions | mm | 1070*100*35 | 1070*100*35 | |||
| Aisle width for pallet 1000*1200 | Ast(mm) | 3410/2990 | 3410-2990 | |||
| Aisle with for pallet 800*1200-transverse travel | Ast(mm) | 3370/2950 | 3370/2950 | |||
| Trurning radius (pedal extended /cloased) | Wa(mm) | 1915/1495 | 1915/1495 | |||
| F u n c t i o n | Travel Speed -laden/unladen | km/h | 4.0/5.8 | 4.0/5.8 | ||
| Lift Speed -laden/unladen | mm/s | 70/125 | 70/125 | |||
| Lowering speed -laden/unladen | mm/s | / | / | |||
| Gradeability -laden/unladen | % | 8/10 | 8/10 | |||
| P o w e r | Drive Motor type | AC | AC | |||
| Driving Motor (S2 60) | kw | 1.5 | 1.5 | |||
| Lift motor type | DC | DC | ||||
| Lift Motor (S3 15%) | kw | 2 | 2 | |||
| Battery V/AH | V/AH | 24/210 | 24/210 | |||
| Weight | Battery | kg | 200 | 200 | ||
| Service Weight | kg | 1835 | 1835 | |||
| Steering | Steering type | Mechanical | Mechanical | |||
| Parking Brake | Electromagnetic | Electromagnetic | ||||
| Parking Operation type | Mechanical | Mechanical | ||||
| Service Brake type | Electromagnetic | Electromagnetic | ||||
If you have any requirements or promotion on that,pls don't hesitate to contact with us.
