1.5T Mini Electric Pallet Truck TE15B

FOB Price

US$ 1,000 - 50,000 / Unit

1 Unit(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Anhui, China		Brand Name	MIMA
Model Number	TE15B		After-sales Service Provided	Engineers available to service machinery overseas

1.5T mini electric pallet truck TE15B;
With batter performance and competitive price;

1.6T Mini electric Pallet Truck TE15B,

1.It's Battery Power with DC drive motor;

2.Built-In charger is easy for charging;

3. PG controller can improve the stability of machine;

4. 24V/80AH High power battery with long working time;

5. Famous curtis power meter with high quality;

MODEL NO.			TE15B
Standard	Power Type		Battery
	Operate Type		walkie
	Rated Capacity	Q(kg)	1500
	Load center	C(mm)	600
T & y R r I e m	Wheel Type-Front/Rear		polyurethane tire
	Front Wheel		φ78*76
	Rear Wheel		φ210*70
	Caster wheel		/
	Tyres No. -front/rear (X=Drive wheel)		4 /1X
	Handle Height	h1(mm)	1145
	Fork Lift Height	h2(mm)	110
	Fork Min Ground Clearance	h3(mm)	85
	Overall Length -pdeal extended/closed	11/12(mm)	1618
	Wheel Base	y(mm)	1291
	Bearing Distance	x(mm)	970
	Fork Dimensions	mm	115015045
	Overall Width	b1(mm)	564 / 684
	Outer width of forks	b2(mm)	560 / 680
	Inner width of forks	b3(mm)	260 / 380
	Tread Front/rear	b4/b5(mm)	410 / 530
	Trurning radius	Wa(mm)	1419
	Aisle width for pallet 800*1200	Ast(mm)	2084
	Aisle width for pallet 1000*1200	Ast(mm)	2173
P o w e r	Drive Motor type		DC
	Driving Motor (S2 60)	kw	0.75
	Lift motor type		DC
	Lift Motor (S3 15%)	kw	0.8
	Battery V/AH	V/AH	24/80
Weight	Battery	kg	51
Weight	Service Weight	kg	200
Steering	Steering type		Mechanical
Steering	Parking brake type		Electromagnetic

The brand of battery can be changed as your requirements;any requirements or suggestion on that,pls don't hesitate to contact with us.
