pcb soldering machine
- shenzhen
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Leady | |
| Model Number | Solder 320 | Voltage | 220V | |
| Dimensions | 570*550*830mm (L*W*H) | Weight | 50kg | |
| Usage | soldering robot | Certification | CE ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
3 axis automatic soldering robot SD-450II-R
pecifications:
| Model*1 | SD-450II-R | ||
| Operating Range | X.Y Axes (mm) | 300×300 | 200×200 |
| Z Axis (mm) | 100 | 50 | |
| R Axis (*C) | 340 | 340 | |
| Max Bearing capacity | Tool(kg) | 6 | 6 |
| Maximum Speed*2 | X.Y Axes (mm/sec) | 600 | 600 |
| <PTP Movement> | Z Axis (mm/sec) | 300 | 300 |
| Maximum Speed*2 | R Axis(degree/sec) | 600 | 600 |
| Repeatability *3 | X.Y .Z Axes (mm) | ±0.02 | ±0.02 |
| R Axis (degree) | ±0.02 | ±0.02 | |
| External Dimensions | WxDxH(mm) | 635×584×856 | 545 x501 x777 |
| (excluding cables and protrusions) | |||
| Main Unit Weight(kg) | 95 | 65 | |
| Motor system | Precision micro-stepping motor | ||
| Control Method | PTP (Point to Point) control, CP (Continuous Path) control | ||
| Interpolation function | 3-dimensional linear and arc interpolation | ||
| Transmission method | Synchronous belt + precision guide way | ||
| Teaching Method | Remote teaching (JOG)/Manual Data Input (MDI) | ||
| Programming method | Direct teaching using the optional teaching pendant | ||
| Display Teach pendant LCD | 320mm×240mm | ||
| I/O signal port | 8 input/ 8 output | ||
| Program Capacity | File data 300 group/625 welding spot | ||
| Power supply | AC 110/220 V inner switch 300W/350W | ||
| Working temperature | 40 °C - 500 °C | ||
| Application | Applied to kinds of industrial soldering for plane, linear,Arc, 3D.such as PCB,USB electronic components and connect the wires to PCB etc. | ||
*1 2-axes models are also available. *2 Maximum speed cannot be achieved when the robot is bearing its maximum portable load. Specifications may be modified without prior notice to improve product quality. | |||
Advantages:
1. accurate movement in less than ±0.02 mm.Large information storage.
2. it can ensure the accuracy of mechanical repetitive motion less than 0.02 mm .
3. It can record the production information (welding production, solder spot quantity, welding time, total welding time).
4 .Convenient for variety of programming model and features
5. Flexible and various soldering method, while support spot soldering welding and slide soldering welding at the same time.
