HG Free & Energy Saving t5 Led Indoor Tube Light

FOB Price

US$ 23 - 25 / Piece

10 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

LED Light Source	SMD2835	Warranty(Years)	3
Input Voltage(V)	AC100-240V	Lamp Power(W)	15
Lamp Luminous Flux(lm)	1500-1650LM	Lamp Luminous Efficiency(lm/w)	110
Color Temperature(CCT)	Other	Working Temperature(℃)	-20, +50
Working Lifetime(Hour)	50000	Lamp Body Material	Aluminum Alloy
IP Rating	Other, IP20	Certification	CE
Place of Origin	Guangdong, China	Brand Name	ShineLong
Model Number	Other, SL-T54X15-96-X

1.2M t5 Led Indoor Tube Light SPECIFICATION
Absolute Maximum Rating at TA=25°C
Parameter	Absolute Maximum Rating
Rated Input Voltage	AC100V ~ AC240V
Operating Voltage	DC24V CONSTANT
Operating Current	Constant 17mA
Electrostatic Discharge	1500 V
Operating Temperature	-20 ~ +50 °C
Storage Temperature	-30 ~ +50 °C
Material	Aluminum + PC cover
Power consumption	15W
Led Qty	238 PCS
Luminous Flux(Typ)	1400-1600LM
Color temperature	WW:3000-3500k,4000-4500K;PW:5000-5500K; CW:>6000K
CRI	80Ra
Viewing angle	120°
Power Factor	>95
Life Time	30,000-50,000 H
Applications	1. Local Lighting: House / Institutional building / Conference Meeting room/Showroom/Showcase 2.Commercial Lighting: Super-market / Department store/shops 3. Public Place Lighting: School / University / Hospital / Hotel

The advantage of pruducts:

•Patent design for tube shape and product mix

•Isolated power supply and can be replaced easily by hand

•High Illumination 0.06W SMD LED and low light decay

•Patent turntable end cap for different light emitting directions

•Constant LED forwarder current during tube operating

•Temperature difference less than 10°C between inside and outside

•TUV, VDE,DLC,SAA,PSE,UL, CE, RoHS approved

The advantage of factory:

•Complete production lines, including SMD LED, Tube series, Flexible LED stripe series, Mould making and Plastic laminating..

•Advanced equipments for production and testing. For example YAMAHA SMT and American HELLER solder reflow.

•ERP system for factory management.

•Professional production , R&D and SALSE team.

•Big work shop and large production capacity(500,000PCS tubes/month)

•Recyclable, SHINELONG can take back or replace the products after being used

APPLICATION :

FACTORY TOUR:
