Essential products! AWS E6013 ( GBE4313)2.5-5.0mm e6013
- QingDao
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | HSMH | |
| Model Number | E6013 | Material | Cast Iron | |
| Length | 300-450mm | Operating Current | 150-280A | |
| Welding Current | 40-70,50-80,80-120,150-190,180-240A | Operating Temperature | 20-40℃ | |
| Diameter | 2.5mm-5.0mm | Application | shipbuilding,steel structure,boiler |
Product Description
Specifications
1 stable arc,lower spatter,little smoke2 excellent welding performance
3 higher deposition efficiency
E6013 is the most popular mild steel welding rod. It is able to provide excellent welding performace and satisfactory weld can be obtained in all position welding.
Application:It is widely used in ordinary strength mild steel structures especially suitable for intermittent welding to sheet steel and small work pieces as well as cosmetic welding with smooth and shiny appearance.
Chemical Composition of Deposited Metal(%)
| C | Mn | Si | S | P | |
| Standard | ≤0.20 | ≤1.20 | ≤1.00 | ≤0.035 | ≤0.04 |
Mechanical Properties of Deposited Metal
| Yield Point ReH(Mpa) | Tensile Strength Rm(Mpa) | Elongation A5(%) | Impact Value (J) 0°c | |
| Standard | ≥306 | 400-560 | ≥22 | ≥47 |
Feature
excellenttechnologicalproperties
stable arc, less splash
shaped good appearance
easy for removal of slag layer
easy for striking arc and restriking arc
Chemical composition
C: 0.10max, Mn 0.39-0.6, Si 0.30max, S 0.03max, P 0.03max
Package
Size: 2.5MM X 300MM (Packing : 2.5kg/inner boxes 8 boxes/cartons=20kg)
Size: 3.2MM X 350MM (Packing: 5.0kg/inner boxes 4boxes/cartons=20kg)
Size: 4.0MM X 400MM (Packing: 5.0kg/inner boxes 4boxes/cartons=20kg) 1MT/PALLET , 2.5MT /PALLET
