length 250mm-400mm welding electrode aws a5.1 E7018 J506 J506Fe
- QingDao
- T/T Credit Card PayPal
You May Like
-
Stainless steel welding electrodes AWS E308-6/E308L-16/E410-16
-
welding electrodes E6013 E6010 E6011 E7018
-
best quality welding electrode AWS e6013 J421 E4313 e8018-b2
-
welding electrodes ER308-16
-
welding electrodes ER308L-16
-
welding electrode E7018 2.5mm/3.2mm/4.0mm,welding rod e7018 supplier,HSMH welding consumables
Product Details
| Place of Origin | Shandong, China | Brand Name | HSMH | |
| Model Number | E7018 j506fe | Material | Cast Iron | |
| Length | 250mm,300mm,350mm 400mm,450mm | Operating Current | 150-280A | |
| Welding Current | 50-240A | Operating Temperature | 20-40℃ | |
| Diameter | 2.5mm, 3.2mm ,4.0mm, 5.0mm | Application | shipbuilding,steel structure,boiler |
Product Description
Specifications
welding electrode e70181stable arc,lower spatter,little smoke
2higher deposition efficiency
3excellent welding performance
AWS welding rod E 7018
1. Feature:
1)Excellent mechanical performance.
2)high depositiong speed.
3)excellent depositing efficiency.
4)Stable arc, little splash.
5)good welding seam.
6)Suitable for all-position welding work.
2.certificate
3. Application:
used fpr we;domg low carbon steel and low alloy steel structure,
such as ships, vehicles, bridges, boilers and buildings etc.
4. Specifications
1.Diameter: 2.5mm/3.2mm/4.0mm
2. Length: 300mm/350mm/400mm
3.Certificate: SGS/ BV/ISO9001-2008/ICQ/CE/SONCAP/COTECNA
Chemical Composition of the Deposited Weld Metal(%) | ||||
C | Mn | Si | S | P |
≤0.12 | 0.30~0.60 | ≤0.30 | ≤0.035 | ≤0.040 |
Mechanical properties | Yield Point σs(MPa) | Tensile Strength σb(MPa) | Elongation δ5(%) | Akv Charpy V-notch Impact Value(J) | |
Typical | 380 | 460 | 28 | 0°C | 97 |
Specification | ≥330 | ≥420 | ≥22 | ≥27 | |
5. Picture for reference
1) factory
2) product
3) loading and transportation
