Custom Silicone Rubber Button Membrane Switch With PCB And Transparent Window

FOB Price

US$ 0.5 - 3.9 / Piece

500 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Liaoning, China	Brand Name	Geeton
Model Number	GMS	Application	Other, Remote Controller, Industrial Equipment
Keypad Button Material	Rubber

Custom Silicone Rubber Button Membrane Swtich With PCB And Transparent Window

Certification	ISO9001:2008, ISO14001:2008& RoHS.
Components:	LED, metal domes, connector and circuit, all these can be designed and made according to customer requirements.
Electronic characteristics
Circuit rating	35V(DC),100mA,1 W
Contact resistance	10Ω - 500Ω(According the trace length and materials to confirm)
Insulation resistance	>100MΩ 250V(DC)
Contact bounce	≤5ms
Dielectric withstand	250VRms(50 - 60Hz/1 min)
Life expectancy	flat type≥500 million times, tactile type:≥1001 million times
Mechanical Properties
Operating pressure	flat type 57-284g (2-10 Oz),tactile type 170-397g (6-14 Oz)
Switch stroke	flat type 0.1 - 0.5mm, tactile type 0.6 - 1.5mm
Environmental parameters
Operating Temperature	-20°C - +80°C
Storage temperature	-40°C - +85°C
Humidity	40°C,90%-95%,240 hours

Detail of The Product

Other Type Of The Membrane Switch

The Application Of The Membrane Switch

Workshops Pictures

Packaging

Customers Visit

Certifications

Any colours, any logos are acceptable, free samples service, leave an inquiry to know more detail about the Price, Shipping and Discount.
