Membrane Switch Silicone Keypad Label

NO.

Material

Adhesive

Lead Time

Shipment

Payment terms

MOQ

Unit Price

Sample

Products

GMS-076

PC

Printing Water-binder

12 days

10 days

Express/Air

T/T,L/C

100 pcs

$0.5~3.0/pc

OEM service offered. Design service offered. Buyer label offered.

Certification

ISO9001:2008, ISO14001:2008& RoHS.

Components:

LED, metal domes, connector and circuit, all these can be designed and made according to customer requirements.

Electronic characteristics

Circuit rating

35V(DC),100mA,1 W

Contact resistance

10Ω - 500Ω(According the trace length and materials to confirm)

Insulation resistance

>100MΩ 250V(DC)

Contact bounce

≤5ms

Dielectric withstand

250VRms(50 - 60Hz/1 min)

Life expectancy

flat type≥5 million times, tactile type:≥1 million times

Mechanical Properties

Operating pressure

flat type 57-284g (2-10 Oz),tactile type 170-397g (6-14 Oz)

Switch stroke

flat type 0.1 - 0.5mm, tactile type 0.6 - 1.5mm

Environmental parameters

Operating Temperature

-20°C - +80°C

Storage temperature

-40°C - +85°C

Humidity

40°C,90%-95%,240 hours

Appearance

Modern, multicolor

Design

Small size, light weight, thin thickness

Feature

Abrasion resistant, moisture-proof, dust-proof, water-proof

Quality

100% QC and the test in making process

Life expectancy

High lifespan, different types of membrane switch is more than 1 million times.

Operation

Easy to operate, intuitive, safe and reliable, Installation and connection convenience.
