Flat Flexible copper conductor rubber cable 50MM2

FOB Price

USD $0.3 - $30 / Meter

500 Meters(Min.Order)

Port China main port
Payment TermsT/T L/C D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China	Brand Name	JYTOP
Insulation Material	Rubber	Type	Low Voltage
Application	Industrial	Conductor Material	Copper
Jacket	Rubber

Product Description

Specifications

Flat Flexible Rubber Cable
for the drives devices
household electrical instrument
all kinds of portable electrical equipment

1. Standard

Rubber insulated cable with rated voltage up to 450/750V is in accordance with the Chinese national standard GB5013, equivalent to IEC60245. Rubber insulated flexible wire and cable with rated voltage up to 450/750V is in accordance with the standard JB8735, equivalent to IEC60245.

2. Application

The cable is suitable for the drives devices, household electrical instrument, all kinds of portable electrical equipments and electromotive tools at A.C. rated voltage up to and including 450/750V. The long-time max. permissible working temperature of conductor is 60°C.

3. Type, Description and Specification

Chinese Type	Description	Rated Voltage(V)	Qty. of Core	Nominal Cross-Section(mm²)	Application Site
YQ YQW	Light-type Rubber Sheathed Flexible Cable	300/500	2,3	0.3~0.5 2, 3, 4, 5	For portable electric instruments, equipments and tools
YZ YZW	Medium-type Rubber Sheathed Flexible Cable	300/500	2, 3, 4, 5 3+1	0.75~6 1.5~6	For portable electric instruments, equipments and tools and can afford larger external forces
YC YCW	Heavy-type Rubber Sheathed Cable	450/750	1 2 3, 4 5 3+1	1.5~400 1~95 1~150 1~25 1.5~150	For portable electric instrument, equipment and can afford larger external forces and weather-resistance and oil-resistance
