Home > Products > Floor Deck Roll Forming Machine > CNC Color Steel Roof Board Floor Deck Roller Machine
CNC Color Steel Roof Board Floor Deck Roller Machine
- tianjin newport
- T/T
You May Like
-
Galvanized Steel Sheet Floor Deck Roll Forming Line
-
HC Steel Floor Decking Sheet Roll Forming Machine, Floor Tile Making Machine Price
-
CNC Steel Rolling Machine/Floor Deck Roll Forming Machine
-
Floor Decking Sheet Roll Forming Machines
-
Steel Floor Decking Panel Cold Roll Forming Machine
-
China Galvanized Steel Floor Deck Machine Making Machine Quality Choice
Product Details
| Condition | New | Type | Tile Forming Machine | |
| Tile Type | Colored Steel | Use | Roof | |
| Production Capacity | 8-10/min | Place of Origin | Hebei, China | |
| Brand Name | HC | Model Number | HC151 | |
| Power(W) | 33+7.5KW | Voltage | 380V | |
| Dimension(L*W*H) | 12700X1850X1650mm | Weight | 31T | |
| Certification | ISO | Warranty | 1year | |
| After-sales Service Provided | Overseas service center available |
Product Description
Specifications
1.CE and ISO certification2. use for roofing and wall
3. high strength, anti-corrosion
4. One year free warranty
CNC color steel roof board Floor Deck Roller Machine
CNC color steel roof board Floor Deck Roller Machine Parameter
No. | main parameter of Floor Deck Roll Forming Machine | |
1 | Suitable to process | Color steel plate |
2 | Width of the plate | 1500mm |
3 | Rollers | 26rows |
4 | Dimensions | 11.9*1.85*1.51m |
5 | Power | 33+7.5kw |
6 | Thickness of the plate | 1.5mm |
7 | Productivity | 8-10m/min |
8 | Diameter of the roller | Φ100mm |
9 | Weight | About 31.8T |
10 | Voltage | 380V 50Hz 3phases |
11 | Material of the cutting plate | Cr12 |
12 | Hydraulic | 40# |
13 | Processing precision | Within 1.00mm |
14 | Control system | PLC control |
CNC color steel roof board Floor Deck Roller Machine Main Machine
Rolling material: Forging Steel 45#,Rolling galvanization thickness:0.05 mm
Equipment components: Man-made uncoiler-roll forming machine-computer control system-
hydraulic control system-cutting
CNC color steel roof board Floor Deck Roller Machine Production Sample
This type of sheet can be widely used in plant, house, storage and simple steel roof and wall. It has advantage of pretty appearance, durable using and so on.
Sample
We have a professional design team,
Can also design and manufacture according to customer's requirement.
Loading Scene
We also have professional worker in charge of loading to make sure the machine without broken during transportation
ISO certificated
Thank you for your attention about our products. Your support is our progressive force
Hoping have a chance to cooperate with you. Thanks
