2 Port EPON OLT OFSET-5102

2 Port EPON OLT

OFSET-5102 is a small scale office end OLT device of FTTX telecommunication level independently researched and developed by OPTFOCUS Company; it conforms to IEEE802.3-2005 standard; it can provide user with access to comprehensive services such as broadband, voice, IPTV and CATV.

Product features:

    Highly reliable case, strong adaptive capacity to environment

1U case,Good shielding measures.

    Layer 2 aggregation switching

Layer 2 wire-speed forwarding; support rich layer 2 protocols

4K MAC address list

Uplink port supports electronic port modules and optical port modules, which can be configured flexibly as required

     Perfect network management function

Support GUI based graphical interface.

Support in-band management, out-of-band management

Support online upgrade of device software

    Strong QOS function

Support flexible DBA, uplink and downlink traffic rate-limited

Support IP ToS, IEEE802.1p

Port based traffic control, traffic shaping.

Supports up to 256 LLID.

    Rich OAM function

Support ONU automatic identification, automatic finding, and automatic registration

Support the function of automatic loop back test to single link

Strong VLAN function, including VLAN Stacking, Trunk, Translation

Support flexible controllable multicasting, support IGMP snooping

Port features:

     2 PON ports (1.25G)

     2 uplink ports (1G) (electronic ports and optical ports options)

     1 management ports (special software management)

     1 console port

Physical features:

      Frame: 19 inches 1U height

Physical dimension: 440×207×43.6 (L×W×H, unit: mm)

      Power supply: AC 100-240V

Power consumption: 20W

     Temperature: Working temperature: 0~45℃ Storage temperature: -30~60℃ Relative humidity: 10~90% (non-condensing)
