External Power 10/100M Media Converter

BI-DI 10/100M Media Converter

Features

• Complies with IEEE802.3 and IEEE802.3u    10/100Base-TX and 100Base-FX
• MTU size supported 1600 bytes maximum
• Supports pure converter mode data forwarding for extreme low latency
• Built in 128Kb RAM for data buffer
• Supports modified cut-through frame forwarding for low latency
• Optional forward fragments
• 10/100Mbps and full/half duplex automatically configure in TP port
• Supports end fault function (optional)

• MDI/MDI-X Auto Negotiation
• Support EEPROM configuration
• LED Indicators: POWER, FX LINK/ACT, 100, TP LINK/ACT, FDX/COL.
• FCC Class A & CE approved
• LLR, LFP - Link Loss Return (LLR), Link Failure Pass (LFP) features supported
• RoHs compliant
• Only 1 fiber used instead of 2 - WDM BiDi technology
• Stainless steel parts (value added feature)
• Standalone, Wallmount or Hotpluggable in 19' chassis - universal design

Introduction

 The 3C-WDM-100-35-20 &3C-WDM-100-53-20 converter complies with IEEE 802.3 standards. It is designed to convert data signal between 10/100 Base-TX and 100 Base Fx Fast Ethernet. The media converter is connected between Fiber cable and twisted cable segments with network operating smoothly.

This converter can be used as a standard alone unit or a slide-in module to fit the 19 converter rack.
Adopting WDM technology, 3C-WDM-400-35-20 &3C-WDM-400-53-20 takes only one fiber cable to transmit and receive data, which will save half cabling cost for you.

BiDi WDM - Wave Division Multiplexing Technology allows you use just a 1 fiber cable instead of 2, because transmit and receive channels are separated by different wavelenghts.
Also, it does not matters, what type of TX/RX are you using at central side or remote side, they will always operate smooth
