CNC Spring Making Machines GH-CNC428

FOB Price

US$ 1 - 1 / Set

1 Set(Min. Order)

Port SHENZHEN
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	ADTECH
Model Number	GH-CNC428

Product Description

Specifications

1) Cheap CNC spring making machines ;
2) Used to make wire molding etc;
9) High speed automatic CNC spring making machines

GH-CNC428 spring coiling machine Description:

1.GH-CNC428 spring coiling machine is a four-axis computerized compression spring making machine consisting of wire feeding axis, outside diameter axis, space axis and cutting tool axis. The four axes can work independently or synchronously.

2.The upper and lower blocks are driven by two motors independently for controlling the space and cutting tool. The two axes can be exchanged.

3.The space can be adjusted by two methods easily and flexibly: cam inclined knife and shaft pushing.

4The spring outside diameter can be adjusted easily by means of setting the program and the outside diameter axis is working independently.

5.This machine can manufacture the compression springs of any shape without adjusting the mechanical parts and absolutely avoid changing the cam plate.

6.This machine can manufacture various compression springs, oil seal springs, battery springs, taper springs, double-taper springs, safe springs, clip spring as well as various simple wire molding.

Technical paremeters for 4-axis cnc compression spring machine GH-CNC428:

Model	GH-CNC428
Axis	4 Axis
Diameter	0.8~3.0mm
Max Feeding Dia	50mm
Max Feeding Length	unlimited
Max production speed	400RPM
Probe	2set
Cam Servo Motor	2.7kw
Wire Feed Servo Motor	2.0kw
Axis Servo Motor	2.0kw
Coiling Axis	2.0kw
Power AC	three-phase 380V
Dimension	1550 X 900 X 1900mm
Weight	900kg
