Home > Products > HCH High thermal conductivity pad > High conductivity factory price thermal pad
High conductivity factory price thermal pad
- shenzhen
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | KY | |
| Model Number | HCH | Type | Insulation Sheet | |
| Material | Other, silicon | Application | High Voltage | |
| Rated Voltage | >5.0KV/MM | Tensile Strength | 55KG/CM2 |
Product Description
Specifications
-High compressibility, soft and flexible, great conductivity;-Meet with the environmental requirements of ROHS and UL.
Typical applications:
-Laptop
-Communication hardware equipment
-High-speed hard disk drive equipment
-Automobile engine control mould
- Micro processor, memory chip and graphics processor
- Mobile equipment
Physical properties:
Test item | Test method | Unit | Test value of HCH series | |
HCH600 value | HCH500 value | |||
Color | Visual |
| Blue/ Laterite | Blue/Yellow |
Thickness | ASTM D374 | Mm | 0.25 to 5.0 | 0.25 to 5.0 |
Specific Gravity | ASTM D792 | g/cc | 2.85 | 2.7 |
Hardness | ASTM D2240 | Shore C | 30 | 30 |
Tensile strength | ASTM D412 | kg/cm2 | 55 | 55 |
Continuous Use Temp | EN 344 | ºC | -40 to 220 | -40 to 220 |
Volume Resistivity | ASTM D257 | Ω-cm | 3.1*1011 | 3.1*1011 |
Breakdown voltage | ASTM D149 | KV/mm | >5.0 | >5.0 |
Flame Rating | UL-94 |
| V-0 | V-0 |
Conductivity | ASTM D5470 | w/m-k | 6.0 | 5.0 |
