Home > Products > filling machine > 5 Gallon Filling Line
5 Gallon Filling Line
Negotiable
/ Set
1 Set(Min. Order)
- shanghai
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | chenyu | |
| Model Number | QGF |
Product Description
Specifications
5 gallon filling line1.Fully automatic
2.spped:120-1000bph
nology from Taiwan and Germany
4.PLC control
5 gallon filling line
1. Technical parameters:
| Model | QGF-100 | QGF-240 | QGF-300 | QGF-450 | QGF-600 | QGF-900 | QGF-1200 |
| Filling heads | 1 | 2 | 3 | 4 | 8 | 8 | 8 |
| Volume(L) | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 |
| Barrel Size(mm) | Φ270X490 | Φ270X490 | Φ270X490 | Φ270X490 | Φ270X490 | Φ270X490 | Φ270X490 |
| Capacity(b/h) | 80-100 | 200-240 | 250-300 | 400 | 800 | 800 | 800 |
Gas Pressure (Mpa) | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.6 | 0.6 | 0.6 |
Gas Consumption (m3/min) | 0.37 | 0.37 | 0.6 | 0.8 | 1 | 1.5 | 1.8 |
| Moto Power(kw) | 1.38 | 1.75 | 3.8 | 3.8 | 7.5 | 9.75 | 13.5 |
| Rated Voltage | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ |
| Weight(kg) | 680 | 800 | 1500 | 2100 | 3000 | 3500 | 4500 |
2. Machine Picture
external scrubber
barrel lifter
internal scrubber
filler
capper
3.Advantages
It is used for 3-gallon,5-gallon water production,with optional from 100b/h to 1000b/h. Customized
service includes automatic cap puller, internal and external barrel scrubber, cap elevator and heat shrinker,etc.
Our technology from Taiwan and Germany,Our machine have good quality and competitive price,Hope cooperate with you!
