Best Digital multimeter UNI-T UT243
- shanghai ningbo
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | uni-t | |
| Model Number | UT | Measuring Current Range | 50A/250A/1000A | |
| Measuring Voltage Range | 150V/300V/600V | Operating Temperature | Normal atmospheric temperature | |
| Dimensions | 303mm X 112mm X 39mm |
Product Description
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product image
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product data
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
UT240 series is a stable, safe, reliable, portable clamp type harmonic power meter, which set the digital current meter, power measurement and harmonic measurement, and is equipped with powerful measurement and data processing software, which can be used to measure, calculate and display parameters such as voltage, current, active power, power factor, power factor, harmonic analysis and test, power, frequency and so on.
It is suitable for the measurement and maintenance of all kinds of power equipment and power supply line. The UT240 series is the ideal choice for the users who need to carry out the harmonic analysis.
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product attribute
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
| Specifications | Range | Best Accuracy |
| Model | UT243 | |
| AC Current (A) | 50A/250A/1000A | ±(2%+5) |
| AC Voltage (V) | 150V/300V/600V | ±(1.2%+5) |
| Frequency (Hz) | 50Hz~60Hz | √ |
| Active Power (W) | 0.01KW~600KW | ±(3%+5) |
| Apparent Power (VA) | 0.01KVAr~600KVAr | ±(4%+5) |
| Reactive Power (VAr) | 0.01KVA~600KVA | ±(3%+5) |
| Power Factor | 0.3~1 | ±(1%+2) |
| Phase Angle (°) | 0° ~ 360° | ±1° |
| Active Energy (Wh) | 1~9999KWh | ±(3%+5) |
| Features | ||
| Display Count | 10000 | |
| Auto Range | √ | |
| Jaw Capacity | 50mm | |
| True RMS | √ | |
| Auto Power Off | √ | |
| Low Battery Indication | √ | |
| Data Hold | √ | |
| MAX/MIN | √ | |
| Data Logging | 999 | |
| USB Interface | √ | |
| LCD Backlight | √ | |
| Full Icon Display | √ | |
| Single-Phrase 2-Wires | √ | |
| 3-Phrase 3-Wires | √ | |
| 3-Phrase 4-Wires | √ | |
| Phase Sequence Test | √ | |
| Harmonic Analysis | 1~20 | |
| Setup | √ | |
| Input Protection | √ | |
| Input Impedance for DCV | Around 5MΩ | √ |
| General Characteristic | ||
| Power | 1.5V Batteries(LR6)×4 | |
| LCD Size | 46mm X 42mm | |
| Product Colour | Red and Grey | |
| Product Net Weight | 601g | |
| Product Size | 303mm X 112mm X 39mm | |
| Standard Accessories | Test Lead, Batteries, Alligator Clips, USB Interface Cable, Tool Box, PC Software CD | |
| Standard Individual Packing | Gift Box, English Manual | |
| Standard Quantity Per Carton | 5 PCs | |
| Standard Carton Measurement | 480mm X 372mm X 315mm (0.056CBM Per Standard Carton) | |
| Standard Carton Gross Weight | 12Kg | |
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
