Automatic Tinplate Can Roll Forming Machine

FOB Price

US$ 7,000 - 12,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China		Brand Name	Changtai
Model Number	ZDJY120		After-sales Service Provided	Engineers available to service machinery overseas

1.Belong to can making line/production line
2.High precision performance
3.Durable
4.Easy and safe to operate

Automatic tinplate can roll forming machine

Main technical data:

Model	ZDJY120-320	ZDJY120-280
Production capability	30~120Cans/min
Applicable can height	70~320mm	70~280mm
Applicable can diameter	52~180mm
Applicable material	tinplate steel-based
Applicable material thickness	0.15~0.35mm
Applicable material hardness	T2.5-DR8
Compress air consumption	600L/min
Pressure of compress air	0.5 MPa ~0.7MPa
Power	380V , 50Hz , 1KW
Dimension	700×1100×1200mm	650×1100×1200mm
Weight	350Kg	340Kg

Technology process:

Cutting-----rounding-----welding-----coating-----drying------pre-curling and expanding-----flanging-----seaming bottom-----beading and curling

Types of products:

aerosol cans, food cans, beverage cans, chemical cans , paint pot and square bucket.

Semi-automatic tinplate can body round forming machine/rolling machine
