Commercial solar water heater system(JSNP-M053)

FOB Price

USD $100 - $500 / Set

1 Set(Min.Order)

Port Shanghai/Ningbo
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Evacuated Tube	Pressure	Unpressurized
Circulation Type	Direct / Open Loop (Active)	Heating System	Thermosyphon (Passive)
Connection Type	Direct-Plug	Installation	Freestanding
Housing Material	Stainless Steel	Certification	CE, Other, CE, RoHS, ISO9001:2000, CCC, SGS
Capacity	2000	Place of Origin	Zhejiang, China
Brand Name	JISHEN	Model Number	JSNP-M053

Product Description

Specifications

1.Commercial solar water heater system
2.CE,ISO9001,RoHS,CCC,SGS approval
3.OEM offered.
4.Logo can be printed

Commercial solar water heater system(JSNP-M052)

Detailed Product Description:

1) Inner tank material: SUS304-2B stainless steel. Available thickness is 0.25-0.5mm.

2) Outer tank material: color chromed steel or galvanized steel or stainless steel.

Available thickness is 0.25-0.5mm.

3) Vacuum tube: 58x1800mm/58x1500mm/47x1800mm/47x1500mm
Material: high borosilicate glass, three-layer coated vacuum tube. Over 15 years service life. Hail resistance: 25mm.

4) Insulation layer: High density polyurethane foam. Available thickness is 50-70mm.

5) Very popular tank capacity in present markets is 100-300L.

6) Frame: Galvanized steel or stainless steel or aluminum alloy

7)Assistant tank: material is same as main tank, capacity with 5L, 8L, 10L available

Loading quantity information:

Vacuum tube			Tank capacity (liters)	Volume of one completed set	Loading quantity
Dia (mm)	Length (mm)	tube quantities(pcs)		Volume of one completed set	20'GP (28m3)	40'HQ (68m3)
Dia (mm)	Length (mm)	tube quantities(pcs)		(CBM)/set	(sets)	sets
Φ58	1800	12	100L	0.456	59	146
		15	130L	0.57	47	117
		16	140L	0.608	44	110
		18	150L	0.684	40	95
		20	170L	0.76	36	85
		22	190L	0.836	32	78
		24	200L	0.912	30	71
		26	220L	0.988	27	66
		28	240L	1.064	25	61
		30	250L	1.14	24	57
		36	300L	1.368	20	47

Vacuum tube			Tank capacity (liters)	Volume of one completed set	Loading quantity
Dia (mm)	Length (mm)	tube quantities(pcs)		Volume of one completed set	20'GP (28m3)	40'HQ (68m3)
Dia (mm)	Length (mm)	tube quantities(pcs)		(CBM)/set	sets	sets
Φ47	1500	16	100L	0.48	56	134
		18	110L	0.54	50	120
		20	125L	0.6	45	108
		22	140L	0.66	41	98
		24	150L	0.72	38	90
		26	160L	0.78	35	83
		28	175L	0.84	32	77
		30	190L	0.9	30	72
		32	200L	0.96	28	68

For more information,please contact us freely,thanks!
