X-max Promo! 10kw wind generator horizontal axis wind turbine generator 10kw

 Safety & Reliable 10kw variable pitch wind turbine, speed regluated wind power generator 10kw, wind generator 10k

Wind turbine main body price: USD10000.00

( INCLUDING   GENERATOR WITH NACELLE 1set, BLADES 3pcs ,VARIABLE PITCH HUB,TAIL ONLY)

Centrifugal variable pitch control, yaw, auto brake, manual brake protection system, more reliable in rich wind place

Low wind speed start up, pitch regulation, safe system

FD8-10kw install in rich wind place;

FD10-10kw install in normal/low average wind speed place.

1. 10kw pitch controlled wind turbine technical data:

10kw variable pitch wind turbine Output power data:

 FD10-10kw variable pitch wind turbine normal spec:

Variable pitch wind turbine 2kw-50kw:

 Production Capacity: 2000 sets per year

Main market:  US, Canada, Australia, New Zealand, European,

Testing Machinery:

Generator platform test

Spring test instrument

Blade angle test platform

Automatic pitch controlled system instrument

Blade balance adjustment instrument

Blade weight center test platform

Turbine turn-to-turn test system

......

CE, ISO,IEC approved

   Recommend for

•  home, garden, signal station, army, island,farm...

10kw wind power generator can be used with solar panels to provide more reliable year-round energy supply.

3.  Pitch controlled element

Rotating speed change of wind rotor drives the centrifugal pitch control mechanism to adjust blade pitch; wind pressure on wind rotor will reduce, and then wind turbine rotating speed slow down. Close loop control, reliable regulation.

Pitch control mechanism is sensitive, reliable, and can be used in variable environments.

Wind turbine start up: keep a big blade pitch, start up with 3m/s wind speed;

Wind turbine start to run: reduce blade pitch step by step, better for speedup;

4-12m/s wind speed: regulate the optimum blade pitch to keep the max output power of wind turbine;

Encountering to strong wind: adjust blade pitch into negative angle to keep rotating speed within limits;

Manual stop: operate manual winch to adjust blade pitch into negative angle, blade will lose it aerodynamics, start mechanical brake to stop wind turbine.

4. 10kw pitch controlled wind turbine advantages

1.) Leading centrifugal pitch control technology

5kw pitch controlled wind turbine, centrifugal pitch controlled mechanism of Wind turbine adjusts blade pitch following wind rotor rotating speed, and keep wind turbine at rated rotating speed. The wind turbine has a stable output power and safe running and is maintenance free.

2.) Auto protection system: APS System

Auto protection system, is selfdeveloped system. When wind speed is over 30m/s or output votlage is over rated, protection system will stop wind turbine, when wind speed is suitable, it will release wind turbine again

3.) Blade technology:

Choose aerofoil through wind tunnel test, optimize design according to aerodynamics, self design and manufactured blade. 5kw wind turbine blade has high efficiency and wide TSR. It is approved by relating dept and all of the users.

Vacuum mould blades with protection film

C.W blades, low noise level, high efficiency

FRB material, 3 pcs blades per set

Adjust blades rotor balance before delivery

 4.)  Generator technology:

Direct drive, wind rotor matches PM generator in optimum TSR High efficiency, low start-up torque.

Allow continuous running in over speed and over load condition 1.5 times of rated speed and power

Maintenance free

5.) Installation technology:

tilt-up tower, particular patent technology, save installation cost

6.) 30% more electricity generated

5kw pitch controlled wind turbine double-grade pitch controlled system not only guarantees optimum efficiency of wind rotor, wind turbine safety and steady output power when the wind speed is higher than rated wind speed, but also makes sure the system can trace the optimum tip speed ratio when the wind speed is lower than rated wind speed to make the wind turbine easy startup, good wind rotor efficiency and more power generation at low wind speed zone.

7.) Multiple protection measures

Leading eadge protection finishing:reduce 10% wind rotor noise, good anti-corrosion capability, prolong service life effectively

 5. Working system

On grid working system:

10kw wind turbine with tower + PWM on grid controller with dump load + 10k/15 grid tie inverter;

On grid system wiring diagram

Off grid working system:

10kw wind turbine with tower + PWM off grid controller with dump load+ battey group + pure sine wave inverter

6.Tower type: guy wire tower, stand lone tower, tilting up tower, hydraulic tower (optional)

Tower height can be manufacture according to user's request.

The tower with  hot-galvanize.

We provided the tower foundation drawing after confirm the tower type, tower height.

7. Matched controller

Controller converts 3 phrase AC power to Dc and charge to the battery group or feed to the grid tie inverter.

Controller with auto brake function, PWM voltage stablization function.

Matched with off grid single phrase/ 3 phrase pure sine wave inverter.

On grid system grid tie inverter ABB power one inverter, our provided grid tie inverter.

 8. Matched grid tie inverter 10k/15k, pure sine wave inverter single phrase/ 3 phrase

 Workship, office building,stock...
