space frame construction steel structure

Specifications

Since 1993•Top 2 iron and steel product manufacturer in Hebei China

3000 employees •4 roll mills on your service

International Quality Management System Certificate ISO9001:2000

Annual output of steel products reaches 1000,000 tons

Space Frame

A space frame or space structure is a truss-like, lightweight rigid structure constructed from interlocking struts in a geometric pattern. Space frames can be used to span large areas with few interior supports. Like the truss, a space frame is strong because of the inherent rigidity of the triangle; flexing loads (bending moments) are transmitted as tension and compression loads along the length of each strut.

In a space-frame, or tube-frame, chassis, the suspension, engine, and body panels are attached to a skeletal space frame, and the body panels have little or no structural function.

Space frames are a common feature in modern construction; they are often found in large roof spans in modernist commercial and industrial buildings.

Space frames are typically designed using a rigidity matrix. The special characteristic of the stiffness matrix in an architectural space frame is the independence of the angular factors. If the joints are sufficiently rigid, the angular deflections can be neglected, simplifying the calculations.

1.Service scope:we can provide fabrication or installation or EPC construction service based on the information and the requirements from Client.

2.Standards applied:Material standard: Q235,Q345 based on China material standard.

3.Application scope;Industry: workshop, warehouse, and other industrial facilities. Commerce: mall, hotel, exhibition hall, hospital, office building.Public: the social activity center, school, library, sports stadium, church etc.

4.Advantage:Steel structure: light weight, high operational reliability ,earth-quake resistance, impact resistance, high degree of industrialization, easy to install.

5.If client can provide the following information in his inquiry, it will be very helpful:design drawing or fabrication drawing if you have.The design load: wind load, snow load, raining condition, geological condition, aseismatic requires.The dimension: length, width, height at least.The function of building, and if need the interior equipment.The special requirements on function, such as plumbing and electric equipment etc.
