5GHz MIMO Sector Antenna 18dBi
- 0 per Month
- Credit Card PayPal
You May Like
Product Details
| Place of Origin | Taiwan, China | Brand Name | ALFA | |
| Model Number | ASA-5819M-120 |
Product Description
Specifications
5GHz MIMO Sector Antenna 19dBi 120 degreeApplications
- Point to Point
- Point to Multi-Point
- Backhaul / Client Antenna
Features
•Dual Polarity
•All Weather Operation
•Includes tilt and swivel mast mount kit
Specifications
Model | ASA-5818M-120 |
Frequency Range | 5.1 ~ 5.9GHz |
Antenna Type: | Directional |
Gain | 19dBi |
VSWR | 1.3:1 |
Horizontal Beamwidth | 120° |
Vertical Beamwidth | 4° |
Impedance | 50Ω |
Maximum Input Power | 50W |
Connector | 2x N Female |
Dimension | 725 * 130 * 60 mm |
Weight | 3 kg |
Mount Style | Pole mount |
Polarization: Vertical
Horizontal
