24KEYS RF LED Controller with Remote

FOB Price

US$ 1.2 - 3.3 / Set

10 Sets(Min. Order)

Port Shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	Ranger
Model Number	RL-RF	Type	Remote Control
Max. Load Power	144	Voltage	Other, 5-24, DO NOTE When Place order

Product Description

There are Four Items for this kind of Controllers

Please Choose right Pictures, if there is any question, please inquiry, we will reply soon.

Supply voltage: DC5V, 12V ~ 24V optional (ordering the required voltage)
Single Dimensions: 61 * 35 * 22mm Single Package Size: 90 * 60 * 40mm
Single Weight: 49g Single GW: 60g
Output: three CMOS open-drain output Connection: common anode, common cathode optional
With speed and brightness adjustment function, with the specified color selection function
Static power consumption: <1W Output current: <2A (each channel)
Output power: 5V: <30W, 12V: <72W, 24V: <144W
Carton Packing: 385 * 315 * 210mm / 100 units;
Carton Packing: 415 * 315 * 385mm / 200 units

Installation Notice:
1) Make sure the connection is correct according to the diagram
2) Pay attention to the parameters limit of voltage. DO NOT run over the peak value
3) Keep the surface of installation clean and smooth avoid breaking off
4) Avoiding the crook area just the position of LED and other components, in order to protect the product and extend the life span of the product

Advantage:
1.Environment friendly.
2.Long lifespan and Energy-saving.

3.Experienced employees that capable for good service

4.Considerate and kind sales-after service.

5.Strict QC procession, ensure each product is high quality.

Please make an inquiry to get more details about this items,
