700-960/1700-2700MHz Patch type LTE 4G Antenna
- Taiwan
You May Like
Product Details
| Place of Origin | Taiwan, China | Brand Name | OEM | |
| Model Number | PTA-0727-01 |
Product Description
Specifications
700-960/1700-2700MHz Patch type LTE 4G Antenna(a) Dual band
(b) 1-3 dBi
(c) 3M adhesive
d) for LTE/GSM/UMTS/3G/WIFI
MODEL : AN- PTA-0727-01
Description : 700-960/1700-2700MHz 1-3dBi L TYPE PATCH ANTENNA +RG174(3M)+SMA PLUG
SPECIFICATION :
1. Antenna Type : Rectangle Patch antenna
2. Operating Frequency: 700-960/1700-2700 MHz
3. Gain : 1-3dBi
4. Power 10 Watts
5. VSWR < 1.9 : 1
6. Impedance 50 ohms
7. Polarization: Vertical
8. Dimensions 132 X 22.5 X 7 mm
9. Mounting Double side tape
10. Connector : FME / SMA (optional)
11.Cable Type : RG174
12. CABLE Length : 3 Meters
SPECIAL FEATURES :
A. Global system for mobil communication.
B. Broadband design for LTE/GSM/UMTS/3G/WiFi wireless
