Home > Products > V1.4 /3D HDMI Splitter > HDMI Splitter 1x8 3D HDCP 1.4V
HDMI Splitter 1x8 3D HDCP 1.4V
- ShenZhen
- T/T Credit Card
You May Like
-
Review 8 Port HDMI Splitter 1.4v 1 in 8 Out Adapter With High Quality
-
Review 8 Port HDMI Splitter 1.4v 1 in 8 Out Adapter With High Quality
-
1.4V HDMI 1x2 Splitter
-
4K HDMI Splitter, 1x2,
-
Full 1080p Supported 2-way HDMI Splitter 1x2, OEM/ODM Service Welcomed
-
HDMI Splitter and Switcher 2 X 8, Supports IR Remote Control, 3D, SIL + PI, Chip-set Design
Product Details
| Brand Name | LSM | Model Number | LSM0108N | |
| Place of Origin | Guangdong, China |
Product Description
Specifications
8-port hdmi splitter 1.4v ,1.Support Full HD, Full 3D
,Support CE FCC ROHS,Support
4Kx2K resolution,Support CEC
OEM/ODM
8-port hdmi splitter 1.4v
FEATURES
l One HDMI 1.4a input signal split to eight HDMI 1.4a sink devices
l Support Full HD, Full 3D
l Support 4K*2K resolution
l Support CEC
l Support deep color 30bit, 36bit, 48bit
l Support Blue-Ray 24/50/60fs/HD-DVD/xvYCC
l Digital audio format, as DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3
/DSD/HD(HBR)
l Support signal retiming
l Support input up to 15metres AWG26 HDMI standard cable length,
output up to 20metres AWG26 cable length
l No loss of quality
l Installs in minutes
l Need DC12V/3A power supply
SPECIFICATIONS: HDSP0108N
HDMI version…………………………………………….………………………………….. HDMI 1.4a
HDMI resolution ……………………………....24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support video color format ……………………...……..….……..24bit/deep color 30bit,36bit, 48bit
Support audio format……..….DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD HD(HBR)
Max bandwidth……………………………………………………….………………………….340MHz
Max baud rate…………………….………………….………………………………………..10.2Gbps
Input/Output TMDS signal ………….…………………………..………... …..0.5~1.5Volts p-p(TTL)
Input/Output DDC signal ……………………………………………..……...……… 5Volts p-p (TTL)
Input cable distance..…... ……………………….…………………...………….≤15m HDMI AWG26
Output cable distance…………………………….……….…...≤20m AWG26 HDMI standard cable
Max working current………………………………..……………………………………………..... 2A
Power adapter format..Input: …………….....AC (50HZ, 60HZ) 100V-240V; Output: DC12V/3A
Operating Temperature range……..…………….……………………………….…… (-15 to +55°C)
Operating Humidity range………………………….….…………..5 to 90%RH (No Condensation)
Dimension (L x W x H)……………………………….……………………….. 280X138X25(mm)
Weight…..………………………………………………………..…….…………………..………871g
