FGB4-1M Cloth Wheel and Linen Wheel Sewing Machine for Thick Materials
- China main seaport or airport
 - Credit Card

You May Like
-


FGB4-1 High Performance Bag Sewing Machine
 -


FGB4-1 FIBC Sewing Machines
 -


FGB4-1 High Performance Container Bag Sewing Machine
 -


FGB4-1 FIBC Sewing Machines Industrial, Container Bag Sewing Machine
 -


FGB4-1 High Performance Industrial Sewing Machine for Container Bag
 -


PP Woven Bag Sewing Machine FGB4-1(industrial Sewing Machine)

Product Details
| Condition | New | Application | Other, industrial | |
| Packaging Material | Other, cloth wheel, linen wheel and other thick materials | Automatic Grade | Automatic | |
| Driven Type | Electric | Voltage | 220V/380V | |
| Power | 550W | Place of Origin | Hebei, China | |
| Brand Name | ShenPeng | Model Number | FGB4-1M | |
| Weight | 135Kg | Certification | ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
FGB4-1M cloth wheel and linen wheel sewing machine for thick materials
Applications
FGB4-1M high performance cloth wheel and linen wheel sewing machine adopts single-needle and oscillating shuttle, upper and lower synchronized feeding, forms 2-thread lock stitch. The manual presser could be pulled in forward, backward, left and right directions.
Features
1. This machine improved the sewing thickness on the basis of FGB4-1.
2. It could be equipped with synchronizer for automatic sewing round plate,which could improve the
sewing speed and sewing quality efficiently .
3. It is suitable for sewing products with thicker material.such as linen wheel and cloth wheel.
4. Big feed force basing on top and bottom feed.
5. 29mm height of max. presser foot lift, suitable for sewing extra heavy duty products.
6. Feed in top and bottom, easy to sew the extra material.
7. single-needle 2-thread lock stitch.
Specifications
Model  | FGB4-1M  | |
Max. sewing speed  | 800r.p.m  | |
Stitch length  | 0-14mm  | |
Needle bar stroke  | 58mm  | |
Presser foot lift  | Standard  | 16mm  |
Max.  | 29mm  | |
Needle size  | 7X200/230/250/300  | |
Working Space  | 220X420mm  | |
Lubrication  | Manual  | |

The service we can provide:
1.Professional technical consulting;
2.Machine operating analysis;
3.Stitch sample making;
4. Provide sewing machine working video ;
5.Maintenance and spare parts services.
FAQ:

1. Q: Do you have your own export right ?
A: Yes, we are able to export the sewing machine to any country or region
2. Q: What service you can supply?
A: Model recommendation, sample making, technical consulting, after-service support
3. Q: Could i visit your factory ?
A: Yes, at the same time you can enjoy more favorable price if buy sewing machine
4. Q: Is your machine could replace Union Special or Newlong sewing machine function?
A: Yes. Our machine could 100% replace Union Special or Newlong sewing machine function.
5. Q: Do you supply spare parts?
A: Yes, Our company produce sewing machine and spare parts by our selves and with fast lead time,best price.
6. Q: What gurantee you supply?
A: Limited spare parts one-year guarantee, not including quick-wear parts like needle, looper, throat plate, feed dog, etc.
