Home > Products > Single output Dinrail power supply > 30W Din Rail power supply DR-30W-12V/2.5A

30W Din Rail power supply DR-30W-12V/2.5A

FOB Price

USD $2.99 - $23.99 / Piece

100 Pieces(Min.Order)

Supply Ability 50000 Piece / Pieces per Month
Port Ningbo/Shanghai
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	Minsen, Minsen
Model Number	DR-30-12	Output Power	1 - 50W
Output Type	Single	Input Voltage	Other, 110-220v
Output Voltage	12V	Output Frequency	47-63Hz
Output Current	2.5A

Product Description

Specifications

1,30W Din Rail power supply
2,High quality and low working temperature
3,CE ROHS certificated
4,OEM is welcomed

Model :30w Din Rail power supply DR-30W-12V 2.5A

Features:
1. Low price and high reliable.
2. 105 `C output capacitor
3. AC input power suitable for the world
4. High efficiency and how operation temperature.
5. Soft-start current can reduce the AC input impact effecticly.
6. With short-circuit and overload protection.
7. Compact size, light weight.
8. 100% full-load buming test.
9. installed with EMI filter, minmum wave.
10,
Specification:
1,With CE,ROHS,ISO9001 certificates
2,OEM,ODM are allowed.
3,Warrabty:2years.
4,For more detail information ,please feel free to contact us and we would appreciate for your asking.
5,We would provide the best service and your satisfaction is our top glory.
6,looking forward your enquiry.

7, 30w Din Rail power supply DR-30W-12V 2.5A

MODEL		DR-30-5	DR-30-12	DR-30-15	DR-30-24
OUTPUT	DC VOLTAGE	5V	12V	15V	24V
	RATED CURRENT	3A	2A	2A	1.5A
	CURRENT RANGE	0 ~ 3A	0 ~ 2A	0 ~2A	0 ~ 1.5A
	RATED POWER	15W	24W	30W	36W
	RIPPLE & NOISE (max.)	80mVp-p	120mVp-p	120mVp-p	150mVp-p
	VOLTAGE ADJ. RANGE	4.75 ~ 5.5V	10.8 ~ 13.2V	13.5 ~ 16.5V	21.6 ~ 26.4V
	VOLTAGE TOLERANCE	±2.0%	±1.0%	±1.0%	±1.0%
	LINE REGULATION	±1.0%	±1.0%	±1.0%	±1.0%
	LOAD REGULATION	±1.0%	±1.0%	±1.0%	±1.0%
	SETUP, RISE TIME	100ms, 30ms/230VAC 100ms, 30ms/115VAC at full load
	HOLD TIME(Typ.)	100ms/230VAC 30ms/115VAC at full load
INPUT	VOLTAGE RANGE	85 ~ 264VAC 120 ~ 370VDC
	FREQUENCY RANGE	47 ~ 63Hz
	EFFICIENCY (Typ.)	74%	81%	82%	83%
	AC CURRENT	0.88A/115VAC 0.48A/230VAC
	INRUSH CURRENT(max.)	COLD START 15A/115VAC 30A/230VAC
PROTECTION	OVERLOAD	105 ~ 160% rated output power
	OVERLOAD	Protection type : Constant current limiting,recovers automatically after fault condition is removed
	OVER VOLTAGE	5.75 ~ 6.75V	13.8 ~ 16.2V	17.25 ~ 20.25V	27.6 ~ 32.4V
	OVER VOLTAGE	Protection type : Shut down o/p voltage,re-power on to recover
ENVIRONMENT	WORKING TEMP.	-20 ~ +60ºC (Refer to output load derating curve)
	WORKING HUMIDITY	20 ~ 90% RH non-condensing
	STORAGE TEMP., HUMIDITY	-20 ~ +85ºC , 10 ~ 95% RH
	TEMP. COEFFICIENT	±0.03%/ºC (0 ~ 50ºC)
	VIBRATION	10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
SAFETY & EMC	SAFETY STANDARDS	Design refer to UL60950-1,TUV EN60950-1,EN50178
	WITHSTAND VOLTAGE	I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
	ISOLATION RESISTANCE	I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
	EMI CONDUCTION & RADIATION	Compliance to EN55022 (CISPR22) Class B
	HARMONIC CURRENT	Compliance to EN61000-3-2,-3
	EMS IMMUNITY	Compliance to EN61000-4-2,3,4,5; ENV50204, EN55024, Light industry level, criteria A
OTHERS	MTBF	441.5K hrs min. MIL-HDBK-217F (25ºC)
	DIMENSION	*789356mm (LWH)*
	PACKING	0.27Kg; 48pcs/14Kg/1.02CUFT
