DR 120W 12v 10A regulated din rail power supply with CE approved

FOB Price

USD $2 - $10 / Piece

10 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1.regulated power supply
2.CE RoHs approved
3.1 years warranty
4.76% efficiency

· Din Rail switching power supply

· Competitived price and high reliability

· 105oC Output capacitor

· AC input power suitable for the world

· High efficiency and low operation temperature

· Soft-start current can reduce the AC input impact effeciticly

· With short-circuit and overload protection

· Compact size, light weight

· 100% full-load burn-in test

· Installed with EMI filter, minimum wave

Model performance	DR-120-12	DR-120-15	DR-120-24	DR-120-48
Direct output voltage, electric current	12V 10A	15V 8A	24V 5A	48V 2.5A
Ripple and noise	100MVP-P	100MVP-P	100MVP-P	100MVP-P
Coil in stability	±0.5%	±0.5%	±0.5%	±0.5%
Load stability	±1%	±0.5%	±0.5%	±0.5%
Efficiency	76%	77%	80%	82%
DC voltage adjustable range	±10%	±10%	±10%	±10%
Input voltage scope	110/220VAC±20% 47~63Hz 120~370VDC
Surge current	Cold starting current 15A/115V 30A/230V
Over-load protection	105%~201% cut-off output, self-recovery
Overvoltage protection	115%~135%rated output voltage
The start, the rise, maintain the time	300ms, 50ms, 80ms
Resistance to pressure	Input output: between 3KvAC input and outer covering: between 1.5Kv output and outer covering: 0.5Kv one minute
Isolating resistor	Input output between input and outer covering between output and outer covering: 500VDC/100MΩ
Operating temperature	-10~+50
Standard of security	Conforms to GB4943, UL60950, EN60950
EMC standard	Conforms to GB9254, EN55022 rank B
