Product Details
Place of Origin | Guangdong, China | Brand Name | zzx | |
Model Number | G-300 | Type | Insulator | |
Material | Other, silicone | Application | High Voltage |
Product Description
Heat resistant grease application in computer heat dissipation module
Thermal conductive silicone grease, this product with good thermal conductivity and insulating properties of metal oxides with the silicone compound into a paste. Product has excellent heat conductivity, good electrical insulation, wide working temperature (operating temperature:-50 ° c ~+200 ° c), good stability, low consistency and good construction performance, this product is non-toxic, corrosive, odorless, not dry, not dissolved.Products can be use in any electronic product ,Such as the CPU and heat sink to fill gaps, high power triode, diode thruster components, and base materials (aluminum, copper) contact at the crack of heat transfer media.
Features
.Thermal conductivity: 2.0/3.0/5.0 W/M-K
. Low thermal resistance
. RoHS & UL compliance
Applications
. CPU and Chipset cooler
. Switching mode power
. Electronic Home compliance
. LED industry
. Others
Store Method:
. This item can be saved for 18 months when it is sealed under room temperature 25°C.
Physical Properties:
PROPERTY | G-200 | G-300 | G-500 | TEST METHOD | UNIT |
Density | 2.3 | 2.7 | 3.2 | ASTM D792 | --- |
Color | Gray | Gray | Gray | --- | Visual |
Volatile Content | 0.5 | 0.3 | 0.2 | ASTM E595 | %/Wt |
Thermal Conductivity | 2.0 | 3.0 | 5.0 | ASTM D5470 | W/mK |
Thermal Resistance | 0.041 | 0.025 | 0.009 | ASTM D5470 | C-In2/W |
Breakdown Voltage | 1100 | 1000 | 600 | ASTM D149 | VAC/mil |
Dielectric Constant | 4.5 | 4.7 | 4.8 | ASTM D150 | --- |
Volume Voltage | >1013 | >1013 | >1012 | ASTM D257 | --- |
Work Temp | -50°C to 200°C |
Description :
high thermal conductivity silicone grease G300 , it absorb the moisture in the air at room temperature curing neutral organic silicon sealing material, not heating curing. It for the vast majority of material, have good adhesive sealing performance, protect electronic products in harsh conditions.
Characteristics After Curing:
1. Avoid moisture, dirt and other atmospheric composition
2. Relieve mechanical, thermal shock and vibration of mechanical stress and tension.
3. Have excellent electrical insulating performance.
4. Outdoor aging, excellent service life up to 20-30 years
5. In the -50-200 °C it has stable mechanical and electrical properties
6. Fire resistance
