Wet Wheel Mill for Gold of Low Investment and Chinafamous Brand
- Qingdao/Shanghai/Guangzhou/Shenzhen/Tianjin
- T/T D/P D/A Credit Card PayPal
You May Like
-
Grinding for Gold of Stable and China Professional
-
Gold Wet Pan Mill of Excellent and Widely Used
-
Wet Grinding Gold Machine of Best Performance and High Capacity
-
Grinding Gold Machine of China Leading Brand and Best Service
-
Gold Wet Pan Mill of Best Quality and China Professional
-
Gold Grinding Mill of Best Quality and Can be Tailored
Product Details
| Condition | New | Type | Ball Mill | |
| Motor Type | AC Motor | Power(W) | 7500-25000 | |
| Capacity(t/h) | 100 | Place of Origin | Henan, China | |
| Brand Name | Dongfang | Model Number | NJ-1600 | |
| Dimension(L*W*H) | 1600*400*200mm | Weight | 5.5-14.5t | |
| Certification | ISOCE | Warranty | within one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Wet wheel mill for gold of Low investment and Chinafamous brand
The wet wheel mill for gold is our star product of our factory.Every time we cooperate with our customers with the viewpoint of long term cooperation.o(∩_∩)o
Description:
Wet wheel mill for gold ,it is also called roll gold machine, is mainly used to separate gold, silver, lead, zinc, molybdenum, iron, copper, antimony, tungsten, tin and other minerals .
Features :
Our wet wheel mill for gold is of less investment,
low cost fast efficiency, small space occupation, saving power, sturdiness and durability, easy maintenance and high return on investment. It is the most suitable production for alternative ball mill, is ideal for small and medium enterprises dressing.
Our factory has many types and many choices to choose for you .
Technical Parameters:
Model | Specification | Input size(mm) | Rotate Speed (r/min) | Powder(kw) | Weight(t) |
1600A | 1600×400×200×500±20mm | 30mm | 20-22 | 25KW | 14.5 |
1500A | 1500×350×200×460±20mm | 20-22 | 22KW | 13.5 | |
1500B | 1500×350×150×460±20mm | 20-22 | 22KW | 12.3 | |
1500C | 1500×300×150×420±20mm | 20-22 | 22KW | 11.3 | |
1400A | 1400×250×150×350±20mm | 16-18 | 18.5kw | 8.5 | |
1400B | 1400×250×150×350±20mm | 21-23 | 18.5kw | 8.5 | |
1350A | 1350×250×150×350±20mm | 16-18 | 18.5kw | 8 | |
1350B | 1350×250×150×350±20mm | 21-23 | 18.5kw | 8 | |
1300A | 1300×250×150×350±20mm | 16-18 | 15kw | 7.5 | |
1300B | 1300×250×150×350±20mm | 21-23 | 15kw | 7.5 | |
1200A | 1200×200×80×250±20mm | 17-19 | 7.5kw | 5.5 | |
1200B | 1200×200×80×250±20mm | 23-25 | 7.5kw | 5.5 | |
1100A | 1100×200×80×250±20mm | 17-19 | 7.5kw | 5 | |
1100B | 1100×200×80×250±20mm | 23-25 | 7.5kw | 5 | |
1000 | 1000×200×80×250±20mm | 13-15 | 5.5kw | 4.5 |
Application :
The wet wheel mill for gold is mainly used for separating gold,sliver,lead,zinc,iron,molybdenum,copper,antioumy and so on.It is the most excellent equipment which can take place of ball mill.Wet pan mill is a perfect equipment for mediunsized and small enterprises.
Operation process:
1.When inputting gold sand into the rolling drum, the rollers compress the sand over and over into tiny particles.
2.Please put in 5 kg mercury at first, the mercury can absorb the gold or other metals.
3.At last, use a high-density red cloth to wrap mercury up.
4.Then squeeze it, the mercury will be pressed out and pure gold stayed.
5.As to the large capacity, we can use mercury shaking machine and mercury steamer to replace the manual work.
Pictures of delivering :
The pictures for delivering goods
Company Introduction:
Henan Dongfang Group is a manufacture factory ,where we produce civilian industry products .The factory has very rich experience as it has a history of more than ten years. The factory covers more than 60,000 square meters,180 sets of gold processing equipment,more than 1,000 employees,and our factory .

You 're welcome to visit our factory and patronize for our common development creating brilliancy!
Contract Us:
HENAN DONGFANG MACHINERY Co., Ltd.
Contact: Helen Zhao
Skype: dfmachine01
Tel: 0086-371-67668877 / 67944555
Fax: 0086-371-67944555
If you have any problems. Please feel free to contact us.
You're warmly welcome to visit our factory
Our website: http://hndongfang.en.china.cn/
