8mm Copper Rod Breakdown Machine (9Dies)
- shanghai
- T/T
You May Like
-
Copper Wire Drawing Machine
-
Big Copper Wire Drawing Machine
-
LZ10-560 Steel Wire Drawing Machine(Cable Making Machine)/wire Coil Machine
-
Straight Line Wire Drawing Machine LZ-560
-
2015 New Steel/ Iron/ Copper Wire Drawing Machine and Nail Making Machine
-
2015 High Speed Automatical Copper/steel Straight Type Wire Drawing Machine
Product Details
| Place of Origin | Jiangsu, China | Brand Name | WDS | |
| Model Number | LT9-450 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
copper rod input diameter:8mm,output diameter: 1.78mm-3.30mm
annealing: continuous annealing
Brand Name: WDS
Specifications
copper rod input diameter:8mm, output diameter:2.2-3.2mm
production speed:500meters/s
production capacity: 1800KG/hour (3mm )
copper rod breakdown wire drawing machine (400/9D)
Machine model:wandeshun LT-400/9D
Inlet diameter:8mm
outlet diameter:2.2-3.2mm
number of dies:9
max production speed:520m/s
installed capacity:125KVA (Main motor:AC.110KW,spooler motor:15KW)
drive: frequency inverters
machine dimension:4m*1.5m*1.3m
machine weight:8500kg
production/per hour
1-outletφ3.0mm ,speed 450-500mpm, production :1600-1800kg/hour
2-gear lubrication and drawing lubrication normal temperature approx 60°C.
machine compositions:
pay off stand
drawing machine(including motors)
tensino controller
coiler machine/bobbin type take up machine
electric panel(including connecting cables)
wire pointer machine
welding machine
