GB/T4508 Asphalt elongation tester

FDL-0231 Asphalt elongation tester

Scope

Asphalt elongation tester according to the People’s Republic of standard GB/T4508 “the petroleum asphalt ductility assay”, the industry standard of the People’s Republic of China JTJ052 “road engineering asphalt and asphalt mixture testing procedures” for T0605  Asphalt Ductility Test under the requirements of design, it suitable for the measurement petroleum pitch was stretched to a certain speed in a predetermined condition, and a certain temperature to the length of the fracture, expressed in cm.

Features

1. Asphalt elongation the test tank no screw, guide rails and other means samples easy installation;

2. Asphalt elongation Tester Test stretching the whole process smooth synchronization no jitter, speed uniform ductility accurate;

3. Asphalt elongation analyzer can simultaneously do ductility testing of three samples to facilitate parallel operation;

4. Asphalt elongation tester digital temperature control device, high precision sensor and magnetic circulation pump, water bath full cycle, high precision temperature;

5. Asphalt elongation tester having a trial frame auto return function, 1.5 m return time of about 10 minutes, the operation is extremely easy.

Technical Parameters

1. Power Supply: AC 220V 50Hz;

2. Measuring range: 1.5m (± 10mm);

3. The heating forms: an electric heater heating 3000W;

4. Bath cycle: strong magnetic circulation pump circulating bath;

5. Measuring range: 5 ~ 49 °C adjustable digital display;

6. Temperature accuracy: ± 0.5 °C;

7. Tensile speed: 10 to 50mm/min, frequency conversion step less adjustable;

8. Measurement accuracy: ± 1 mm;

9. Ductility: SCM control, data processing after crop digital display;

10. The refrigeration in the form: 1.25 compressor refrigeration input power 950W;

11. Ambient temperature: -10 to +35 ° C;

12. Relative humidity:  85%;

13. Total power consumption: not more than 4100W.

Packaging Detail: standard wooden case
Delivery Detail: 10 working days after receipt of the advance payment.

1,warranty period, scope, and warranty conditions

" one year warranty, Product maintenance, software upgrades,  installation, Training operators "

2,Speed problem solving

Get a phone call within 2 hours to give back

3,Devices with training, mentoring

Training schedule

Other after-sales service commitment (installation, regular inspection etc. )

During use of the product to send personnel to visit from time to time, to understand the use of equipment, and stored in user profiles

5,

Service Contacts

Contact: Jiang Haihua

Tel :13974982773

other preferential terms

Each year held user classes in Changsha by experienced technical engineers. To provide users detailed training instrument works, methods of operation and routine maintenance and repairs.

Provide instruments easily worn parts

Mission :

Friend Instruments is the leading manufacturer of laboratory and testing equipment. The mission of friend Instruments  is

• To provide user friendly, simplified, technologically advanced, reliable & robust instrumentation/automation to global customers backed by efficient services

• Applying creative innovations and modern techniques  to uplift the standard of quality as to satisfy customers' need of achieving high precision & accuracy in measurement and testing

• Further, to create an enviorment to nurture and promote innovations and core values amongst the employees so as to leave no stone unturned in fulfilling the expectations of customers.

• To deliv er reliability & credibility

Vision :

Vision rules our organization. A framework, a supreme code of conduct cherishes us every day to serve the world better.

• Friend Instruments envisages itself as an emerging organisation standing ahead of the competition through its marketing and manufacturing of the advanced laboratory equipments.

• Frined Instruments evolves itself as a workplace of efficient individuals dedicated to serve the nation & china industry with constant improvement driven by innovation, integrity & inspiration.

1. What's the warranty?

Normally 12 months

2.Does the power supply can customized?

YES ,if you need customized power supply,pls tell us when you put the order.

3.What's the production time?

Usually 20 days for production, some equipments need extra time to debug.

4.What's the Dlivery method ?

Light-weight cargo is usually by express , Air transport and sea shipping is acceptable (provide with safty packing)

5.What's the delivery time?

According to different method and country , express will be 6~15 days

6. How to install and operate?

According to each instruction manual which sent with equipment. ( We also provide after-sale technical support)

7.What's the payment term?

Usually we do 30%TT deposit ,70%TT balance before shipping.LC,Western Union,MoneyGram are acceptable.
