20 years experience Pneumatic Actuator, High Output Power
US$ 15 - 3,000
/ Set
1 Set(Min. Order)
- shanghai/ningbo
- T/T Credit Card PayPal
You May Like
Product Details
| Standard or Nonstandard | Standard | Structure | Angle | |
| Pressure | Medium Pressure | Power | Pneumatic | |
| Material | Alloy | Temperature of Media | Medium Temperature | |
| Media | Water | Port Size | 8.5-5496mm | |
| Place of Origin | Zhejiang, China | Model Number | AT040-AT279 | |
| Brand Name | ZhiTai |
Product Description
Specifications
Dual piston rackIntegrated design
High output power
Integrated design
Long service life
20 years experience Double or single Acting Pneumatic Actuator
Pneumatic actuators :
- Features:
- Dual piston rack
- Integrated design
- High output power
- Integrated design
- Long service life
- Stainless steel fasteners for long term corrosion resistance
- Interface between piston, pinion and body is made of low friction material
- Specifications:
- Pressure range: maximum working pressure 10 bars
- Air pressure: 2.5 to 8 bars
- Adjustment range: 90 ±5°
- Ambient temperature: -20 to +90°C
- Type: single-acting (spring return) and double-acting
- Optional accessories: solenoid valves, limited switch and electric position
- Lubrication: all moving parts are coated with lubricants, extending their service life
- Life time: one million time
- Standards:
- Interface between actuator and valve: 4 or 8 bolt orifices according to DIN/ISO5211, the axle assembles orifice according to DIN 3337
- Interface between actuator and control valve: 7100 D/S-7350 D/S according to NAMUR or VDI/VDE 3845, 7040 D/S-7090 D/S connecting via adapter plate
- Interface between actuator and signal box: according to VDI/VDE 3845
- Introduction:
- Actuator body
- Boy material: aluminium alloy
- Internal and external surface are treated with anodic oxidation and polishing
- Outer surface is nickel plated so that anti-corrosion function of actuator and minimum friction against pistons can be guaranteed
- End cover material is die-casting aluminium
- End cover is treated with epoxy polyester so as to best guarantee the anti-corrosion performance
- Drive shaft material: medium carbon steel
- With fine processing and nickel-plated
