Home > Products > Compound Geomembranes > compound geomembrane with one membrane and geotextile
compound geomembrane with one membrane and geotextile
- 100000 Ton / Tons per Month
- Tianjin port China
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Hebei, China | Brand Name | yuxing | |
| Model Number | 100-800g/m2 | Geotextile Type | Non-Woven Geotextiles |
Product Description
Specifications
color:white,black,blue or as your requiredmaterial:PP PET
width:1-6.2m
thickness:0.9-5.0mm
tear strength(KN):0.08-0.60
Usage:
1. Filtration:The filtration layer of the dykes, river canal, seacoast, concrete slope,retaining walls. At the same
time of preventing the clay granule from passing, it allows the water and the gas pass through freely.
2.Separation:
The isolation of the railway dregs and the roadbed, roadbed and the soft base, surface of theairdrome and
parking lot and the groundsill, different dam materials. It isolates the soil and the gravel of two kinds different
granule pathway from the groundsill or other buildings.
3.Adding muscle:The highway, railway, soil-stone dam, breakwater, airport, backfill soil of retaining wall, slope protection, etc in which distributes the
earth stress, prevents the side-displacement of the earth body and improves the earth body stability.
4 Protection
It prevents the bank from being washed out, protects the bank and the bottom, prevents the water and soil
from being washed away.
specification(g)/m properties | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | 800 | |
Tolerances of weight(%) | -8 | -8 | -8 | -8 | -7 | -7 | -7 | -7 | -6 | -6 | -6 | |
Thickness(mm) | 0.9 | 1.3 | 1.7 | 2.1 | 2.4 | 2.7 | 3.0 | 3.3 | 3.6 | 4.1 | 5.0 | |
Burst strength(KN/m) | 2.5 | 4.5 | 6.5 | 8.0 | 9.5 | 11.0 | 12.5 | 14.0 | 16.0 | 19.0 | 25.0 | |
Elongation(%) | 25-100 | |||||||||||
Tear strength(KN) | 0.08 | 0.12 | 0.16 | 0.20 | 0.24 | 0.28 | 0.33 | 0.38 | 0.42 | 0.46 | 0.60 | |
CBRpuncture Strength(KN) | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 | 2.7 | 3.2 | 4.0 | |
Opening size(O90/O95) | 0.07-0.2 | |||||||||||
Permeability(cm/s) | K × (10-1~10-3) K=1.0-9.9 | |||||||||||
