M10 steel forged with zinc plated eye bolt (DIN580)
- 100 Ton / Tons per Month
- Shanghai/Ningbo/Tianjin/Qingdao/Shenzhen
- T/T
You May Like
Product Details
Place of Origin | China | Brand Name | EW | |
Model Number | DIN580 | Standard | DIN |
Product Description
Specifications
M10 steel forged with zinc plated eye bolt (DIN580)1.Material:steel ,stainless steel
2.size :m6-m100
3.finish:black ,zinc
M10 steel forged with zinc plated eye bolt (DIN580)
Forged Eye bolt, Lifting Eye Bolt, DIN 580 Eye Screw
Surface: Galvanized, zinc plated, chromed plated
Material: Carbon steel C15, C15E, SS, Q235 etc
Type: C15, normal WLL and specification, or as you needed
Packing: Plastic bags, carbon boxes, wood pallets and iron pallets
Thread rolling: Threads under metric system or British system
Packing: Carton +Pallet
User information for lifting eye bolts DIN 580
Eye bolts conforming to this standard are primarily intended as permanent attachments on equipment such as motors, control cabinets, gear boxes,
Etc. When used as temporary attachments on larger objects such as large tools for transportation only, the next largest thread size should be used.
The safe working load values given in table 1 are based on the following assumptions:
The capacity specied in the second line of table 1 applies up to an inclination angle of 45° . The capacity specied in the third line applies for laterally
Inserted eye bolts applies up to an inclination angle of 45° In all directions in regard to the ring level. Lateral pull should not be applied (see picture 2).
Before being used, eye bolts should be checked for correct seating and apparent damage (e. G. Corrosion, deformation). Deformed eye bolts should be
Discarded. In eye bolt assemblies with clearance hole, a washer and nut (not thin nut) should be used.
Detailed size:
M | A | B | C | D | E |
Size | Out circle | Inner circle | Material | Weight/ | Pcs/bag |
6 | 28 | 16 | c15 | 0.05 | 700 |
8 | 36 | 20 | c15 | 0.06 | 700 |
10 | 45 | 25 | c15 | 0.11 | 350 |
12 | 54 | 30 | c15 | 0.18 | 200 |
16 | 63 | 35 | c15 | 0.285 | 125 |
20 | 72 | 40 | c15 | 0.45 | 80 |
24 | 90 | 50 | c15 | 0.87 | 40 |
30 | 108 | 60 | c15 | 1.66 | 25 |
36 | 126 | 70 | c15 | 2.65 | 15 |
42 | 144 | 80 | c15 | 4.03 | 8 |
48 | 166 | 90 | c15 | 6.38 | 6 |
56 | 184 | 100 | c15 | 8.8 | 4 |
64 | 206 | 110 | c15 | 12.5 | 3 |
72 | 260 | 140 | c15 | 23.3 | 1 |
80 | 296 | 160 | c15 | 34.2 | 1 |
100 | 330 | 180 | c15 | 49.1 | 1 |
Photo:
-Packing:
1.packing:small box /bulking packing/roll packing+carton+pallets
Usually,48cartons /pallets
-Shipping
1.by express: DHL,FEDEX,UPS,TNT,ARAMEX,etc
2.by sea
3.by air
1.sample :free sample is ok
2.make your logo label
3.packing as your requirements
4.OEM can be accepted
petitive price and high quality
Application:
1.Question: what's you material, OEM is ok ?
Answer:we have carbon steel and stainless steel material , any material can make as your requirements .
OEM is accepted .if large qty there is no need mould fee .
2.Question: free sample is ok ?
Answer:sample for standard is free. sample fee is need for non-standard . but freight you need to pay for it .
of course , you can save the sample fee and freight if you place the order . special sample will send you to test. then after confirmed large prouction will start.
3.Question:How is your packing ?
Answer:usually about inner packing we have bulking packing(polybag packing) ,roll packing ,small box packing ,then put into the carton , last packed into the pallets .
4.Question: How is your quality.
Answer: we can offer you the related material report or quality export as your requirement.
Sample can offer you to test. about the the quality we can promise you the quality after the goods selled six month . if some wrong happens cause the goods quality ,we will offer you the best solution.
Any questions please send us the email or call me . Thanks and have a nice day!
