ASY-600 Six Color Plastic Bag Gravure Printer Machine
- NINGBO PORT
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | RUIHAO | Model Number | ASY-600/800/1000 | |
| Usage | Other, plastic film ,paper, aluminium foil, etc. | Automatic Grade | Automatic | |
| Voltage | 220V/380V/440V | Gross Power | 32kw | |
| Dimensions(L*W*H) | 8100*2300*1800mm | Weight | 5T | |
| Certification | CE | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.ASY-600 Six Color Plastic Bag Gravure Printer Machine2.1-10 colours
3.without computer
4.CE
ASY-600 Six Color Plastic Bag Gravure Printer Machine
Performance and characteristic:
1. Newest advanced version gear box, 360 degrees not engine offs to version installment.
2. The motion type doctor blade installment, the crosswise reciprocation flees moves.
3. The remote infrared ray preheater pipe drying system can maintain does 60m/min.
4. Puts the volume hauling to use the magnetic powder brake to employ according to ability the material to be steadier.
5. Receives the volume part, the hauling and the volume takes uses the magnetic powder coupling, the color printing is precise, receives the volume end surface to be neater.
6. The electric current output type temperature control system causes the heating fast province electricity.
7. Turns over the double location to take in and put away the volume organization, realizes does not stop meets refueling.
8. The reverse side one time prints continuously.
Main technical parameter:
Model | ASY-A-6600 | ASY-A-6800 | ASY-A-61000 |
Effective printing width | 600mm | 800mm | 1000mm |
Max. width of base material | 620mm | 820mm | 1020mm |
Printing maximum speed |
10to60m/min |
10to60m/min |
10to60m/min |
Max. diameter of rolling and releasing |
600mm |
600mm |
600mm |
Diameter of Printing plate roller |
70to270mm |
70to270mm |
70to270mm |
Set of accurate precision | 0.2mm | 0.2mm | 0.2mm |
Heating power | 14.4kw | 19.2kw | 24kw |
Total power | 22Kw | 27Kw | 32Kw |
Machine weight | 6000kg | 6500kg | 7000kg |
Overall dimension | 8100*1900*1800mm | 8100*2100*1800mm | 8100*2300*1800mm |
