Home > Products > WK Series Helical-bevel Gear Reducer > gear speed reductor
gear speed reductor
US$ 185 - 6,200
/ Piece
1 Piece(Min. Order)
- NINGBO or SHANGHAI
- T/T
You May Like
Product Details
| Gearing Arrangement | Helical | Output Torque | 150 ~28000kNm | |
| Rated Power | 0.12~160KW | Input Speed | 1400rpm(4pole) | |
| Output Speed | 0.16~1028r/min | Place of Origin | Zhejiang, China | |
| Model Number | from WK37 up to WK187 | Brand Name | Wuma or OEM |
Product Description
Product Description
| WK series helical reducer | |
| Efficiency | 94%~98% (depends on the transmission stage) |
| Housing material | HT250 high-strength cast iron |
| Gear material | 20CrMnTi |
| Surface hardness of gears | HRC58°~62 ° |
| Input / Output shaft material | 40Cr |
| Machining precision of gears | accurate grinding, 6 Grade |
| Lubricating oil | |
| Heat treatment | tempering, cementiting, quenching,etc. |
| Brand of bearings | C&U bearing |
| Brand of oil seal | NAK or other brand |
| Noise (MAX) | 65~70dB |
| Temp. rise (MAX) | 40 C |
| Temp. rise (Oil)(MAX) | 50 C |
| Vibration | ≤20µm |
Various types of connection
Drawing of WK37
Quality Control
1. We have passed ISO9001 quality management system.
2. Running test process: each reducer will make running test for 1 hour each side.
3. We use advanced inspection center and measurement to control the size and quality of housing, gears and key parts.
Key processing machines
Packaging & Shipping
Company Information
WUMA was established in 1995, who have over 18 years experience in making gearbox and helical reducers.
WUMA insist on the enterprise spirit of “Forge ahead, (keeping) innovation, quality first, credit principal”.
Our company president Mr.Lu together with all the staff warmly welcome all the friends from all over the world to have sincere cooperation with us and create a better future !
Contact Us
- Zhejiang Wuma Reducer Co., Ltd.
- Contact nameAngela Lu Chat Now
- Phone86-577-85956223
- AddressPuzhou 3Rd., Industry Zone, Wenzhou, Zhejiang
