power contact regulator
USD $500 - $1,500
/ Piece
1 Piece(Min.Order)
- Ningbo or Shanghai
- T/T Credit Card
You May Like
Product Details
Place of Origin | Zhejiang, China | Brand Name | ZMELEC or OEM | |
Model Number | TSGZ-40kVA | Usage | Other, TSGZ | |
Phase | Three Phase | Current Type | AC |
Product Description
Specifications
Three Phase Contact Voltage Regulator/voltage stabilizerInput:380V
Output Adjustable:0-430V or 0-660V
CE and Soncap Approve
TDGZ,TSGZ Series of High-Power Columu Regulator
Feautre
TDGZ,TSGZ series single phase and three phase high power post type voltage regulator is a kind of new product developed and design by our company according to the market demand. To satisfy users’ demands. the waveform of output voltage of this voltage regulator will not distort(distortion rate increment of the output voltage waveform is <1%),adopts electric operating mechanism, it can be closed remote control to reduce work-intensity and the output voltage can be adjusted from zero. Besides, it also has advantages of strong instantaneous overload capability, no-load current, no-load low consumption, high efficiency, low noise, long service life etc. it is suitable for various inductive capacitive and resistive loads.
Model means
TDGZ
T: Regulator
D: Single phase
S: Three phase
G: dry type
Z: Post type
Application
Widely applied to scientific research field, communication system, test equipment, light adjusting and rectification equipment etc.
Detail Specification
Model | Rating Power (kVA) | Phase No. | Frequency (Hz) | Input volt. (V) | Output volt (V) | Output current(A) |
TDGZ-16K | 16 | 1 | 50 | 220 | 0~250 | 64A |
TDGZ-20K | 20 | 1 | 50 | 220 | 0~250 | 80A |
TDGZ-25K | 25 | 1 | 50 | 220 | 0~250 | 100A |
TDGZ-32K | 32 | 1 | 50 | 220 | 0~250 | 128A |
TDGZ-40K | 40 | 1 | 50 | 220 | 0~250 | 160A |
TDGZ-50K | 50 | 1 | 50 | 220 | 0~250 | 200A |
TDGZ-63K | 63 | 1 | 50 | 220 | 0~250 | 252A |
TDGZ-80K | 80 | 1 | 50 | 220 | 0~250 | 320A |
TDGZ-100K | 100 | 1 | 50 | 220 | 0~250 | 400A |
TDGZ-120K | 120 | 1 | 50 | 220 | 0~250 | 480A |
TDGZ-125K | 125 | 1 | 50 | 220 | 0~250 | 500A |
TDGZ-150K | 150 | 1 | 50 | 220 | 0~250 | 600A |
TSGZ-25K | 25 | 3 | 50 | 380 | 0~430 | 33A |
TSGZ-32K | 32 | 3 | 50 | 380 | 0~430 | 43A |
TSGZ-40K | 40 | 3 | 50 | 380 | 0~430 | 53A |
TSGZ-50K | 50 | 3 | 50 | 380 | 0~430 | 67A |
TSGZ-63K | 63 | 3 | 50 | 380 | 0~430 | 84A |
TSGZ-80K | 80 | 3 | 50 | 380 | 0~430 | 107A |
TSGZ-100K | 100 | 3 | 50 | 380 | 0~430 | 134A |
TSGZ-120K | 120 | 3 | 50 | 380 | 0~430 | 160A |
TSGZ-125K | 125 | 3 | 50 | 380 | 0~430 | 168A |
TSGZ-150K | 150 | 3 | 50 | 380 | 0~430 | 200A |
TSGZ-160K | 160 | 3 | 50 | 380 | 0~430 | 215A |
TSGZ-200K | 200 | 3 | 50 | 380 | 0~430 | 269A |
