Fully-automatic Truck-mounted LED Display Screen

Specifications

      1.Colours displayed:Mono-primary color (red,yellowor green)

 2.Dot matrix display:24*96

 3.Pixel reticular density:11000pixel/m2

 4.Temperature:-25~+55

 5.LED (light emitting diode):5mm , Super-high brightness LED

 6.Humidity:Normal working under 98% relative humidity.

 7.Brightness per square metre:8000cd/m2

 8.Work time:Continous work for 24h

 9.Pixel pitch:9.5mm

 10.Visual distance:100m

 11.Brightness adjustment:32Grade

 12.LED life:100000h

 13.Average power:150W

 14.Average No-error time:10000h

 15.Vertical speed of screen:20mm/s

 16.Work current for fluctuation:3A ~ 4A

 17.Display visual angle:<=35°

 18.Power mode:DC12V

 19.Driving mode:Static constant current

 20.Means of communication:Serial Communication

 21.Max power of warning lamp:60W

 22.Flicker Frequency (warning lamp):30-54 times/min

 23.Pulse space within each group (warning lamp):100ms

 24.Light source of warning lamp:Brightness LED

 25.Max power of warner:150W

 26.Function of warner:Alarm whistle,guidance,fire alarm,engineering rescue, ambulance

 27.Screen external size:992mm*384mm

 28.Effective display screen:912mm*228mm

 29.Weight:35KG or 45KG(changes according to the selected material)

 30.Overall external size (folding state):1200mm*600mm*170mm
