2W025 High Pressure 2/2 Way Direct Action Smaill Orifice Solenoid Valve (air/water/steam) Water Valve

FOB Price

Negotiable

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Stable quality
Competitive price
Fast delivery
Plastic package will keep safty when use
Popular with customers

Model	2W025-06	2W025-08	2W040-10	2WH012-06	2WH012-08	2WH020-10
Port Size	G1/8"	G1/4"	G3/8"	G1/8"	G1/4"	G3/8"
Orifice Size	2.5		4.0	1.2	1.2	2.0
CV Value	0.23		0.60	0.05	0.05	0.15
Working Medium	Air,Water,Oil,Gas
Motion Pattern	Direct acting
Type	Normally Closed
Working-pressure	Air,Water,Oil,Gas: 0~0.7MPa			Air, Water, Oil:0~2.0MPa
Max. Pressure Resistance	1.0MPa			3.5MPa
Operating temperature	NBR for-5-80^oC and EPDM,VITON for-5-150^oC
Voltage Range	±10%
Material of Body	Brass or Stanless steel
Material Oil Seal	NBR,EPDM,VITON or SI

Packaging: Carton (or according to customers' requirements)

Loading port: Guangzhou / Shenzhen Seaport

Delivery time: 7-15 days (Depend on your qty)

Sample: Available with freight collected
