Home > Products > Telephone Cable > indoor outdoor telephone cable drop wire
indoor outdoor telephone cable drop wire
- fob shanghai / ningbo
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Huajie or OEM | |
| Model Number | Telephone wire | Type | Coaxial | |
| Number of Conductors | 4 |
Product Description
Specifications
indoor outdoor telephone cable drop wire :1.Factory Competitive price.
2.Timely delivery.
3.ISO9001, CE, ROHS
indoor outdoor telephone cable drop wire :
High performance telephone wire have good quality and competitive price.
Telephone wire
Inner Conductor: Bare Copper or CCS,CCA
Insulation: PVC or PE
Cores Colour: as per Customer's request
Jacket : PVC
Jacket Colour: White or gray or According to the Customer requirments.
Description:
1P, 2*1/0.50 Copper or CCS, OD: 2.6MM
2P, 4*1/0.50 Copper or CCS, OD: 3.2MM
3P, 6*1/0.50 Copper or CCS, OD: 3.6MM
4P, 8*1/0.50 Copper or CCS, OD: 4.1MM
5P, 10*1/0.50 Copper or CCS, OD: 4.7MM
6P, 12*1/0.50 Copper or CCS, OD: 4.9MM
7P, 14*1/0.50 Copper or CCS, OD: 5.2MM
8P, 16*1/0.50 Copper or CCS, OD: 5.4MM
Factory Show :
Cetification :
Packing :
Product list :
RG59 | Specification | |
| Inner Conductor | 0.643/0.813mm BC/CCS |
Dielectric | 3.66mm Foam PE | |
Shield | Al Foil/Bonded Foil | |
Braiding | 40%-95%Braiding | |
Jacket | 6.0mm PVC | |
RG59+Power | Specification | |
| Inner Conductor | 0.64/0.81mm BC/CCS |
Dielectric | 3.66mmSolid PE/ Foam PE | |
Shield | Al Foil/Bonded Foil | |
Braiding | 40%-95%Braiding | |
Jacket | 6.0mm PVC | |
power | 2core*0.75mm2 CCA/CU | |
RG6 | Specification | |
| Inner Conductor | 1.02mm Cu/CCS |
Dielectric | 4.57mm Foam PE | |
Shield | Bonded Foil | |
Braiding | 40%-95%Braiding | |
Jacket | 6.91mm PVC | |
RG11 | Specification | |
| Inner Conductor | 1.63mm Cu/CCS |
Dielectric | 7.11mm Foam PE | |
Shield | Bonded Foil | |
Braiding | 40%-95%Braiding | |
Jacket | 10.02mm PVC | |
QR500 | Specification | |
| Inner Conductor | 2.77mm BC/CCA |
Dielectric | 11.43mm Foam PE | |
Shield | 0.25-0.6mm Al Tube(thickness) | |
Jacket | 14.22mm PE | |
QR540 | Specification | |
| Inner Conductor | 3.15mm BC/CCA |
Dielectric | 13.3mm Foam PE | |
Shield | 0.25-0.6mm Al Tube(thickness) | |
Jacket | 15.49mm PE | |
UTP CAt5e | Specification |
|
| Inner Conductor | 4Pair *0.51mm BC/CCA |
Dielectric | 0.92mm Foam PE | |
Jacket | 5.0mm PVC White/Gray | |
Power Cable | Specification |
|
| Inner Conductor | 0.75,1.0,1.5,2.5,4.0mm2 BC/CCA |
Dielectric | PVC | |
Jacket | PVC White | |
Telephone Cable | Specification |
|
| Inner Conductor | 4Core*0.5mm BC/CCS |
Dielectric | 4Core*1.0mm Insulation | |
Jacket | 3.8mm PVC | |
Alarm Cable | Specification | |
| Inner Conductor | 4Core*7*0.2mm BC/TCCA |
Dielectric | 4Core*1.0mm Insulation | |
Jacket | 3.8mm PVC White | |
Why us ?
1. We are the professional coaxial cable manufacturer, so we have rich production experience on the cables;
2. OEM/ODM is available, your own brand can be printed in both cables and boxes;
3. We have special quality control department to ensure our good quality;
4. Cables are approved based on CE, ROHS, ISO9001 quality standard;
5. Short delivery time, we can finish a 20ft container within 15 days.
