Home > Products > Crusher Equipment > Vibrating Screen
Vibrating Screen
- shanghai
- T/T L/C
You May Like
Product Details
| Condition | Used | Type | Circular | |
| Application | Ore | Place of Origin | Shanghai, China | |
| Brand Name | sievo | Model Number | 2YK2460 |
Product Description
Vibrating Screen
YK Series Circle Vibrating Screen Introduction:,
Vibrating Screen are used to separate materials into various sizes for further processing, or for end use. Depend on our need. The material is separated by passing it through a vibrating “screen box” which has a number of different sized screens, or meshes, which the material falls through like a sieve, the material falls onto attached conveyors which stock pile the end products. The end products can then be used in the building and construction industries.
Features and Benefits:
1. Adopted the eccentric block vibrator, so it not only can strengthen the vibrating force, also can be adjusted randomly;
2. Adopted the tire coupling, so it is flexible connection and steady operation;
3. The screen crossbeam and screen box adopted high-strength bolt, so its structure is simple and easy maintenance.
4. Adopted smaller amplitude, higher frequency, bigger obliquity, so it features higher screening efficiency, larger processing capability, longer service life, easier maintenance, lower electric consumption and noise.
| Model | Spec. | Layers | Screen area | Sieve pore size | Max feed size | Capacity | Weight | Power | Overall dimension |
| (mm) | (m2) | (mm) | (mm) | (t/h) | (t) | (kw) | (L×W×H) (mm) | ||
| 2YK1235 | 1200×3500 | 2 | 4.2 | 5-50 | 400 | 15-100 | 3.2 | 5.5 | 4090×1900×800 |
| 3YK1235 | 1200×3500 | 3 | 4.2 | 5-50 | 400 | 30-100 | 4.4 | 7.5 | 4400×1900×1200 |
| 2YK1545 | 1500×4500 | 2 | 6.75 | 5-50 | 400 | 50-180 | 5.3 | 15 | 5400×2250×1600 |
| 3YK1545 | 1500×4500 | 3 | 6.75 | 5-50 | 400 | 50-210 | 6.1 | 15 | 5400×2250×1700 |
| 4YK1545 | 1500×4500 | 4 | 6.75 | 5-50 | 400 | 50-240 | 6.9 | 18.5 | 5400×2250×1700 |
| 2YK1860 | 1800×6000 | 2 | 10.8 | 5-80 | 400 | 50-330 | 8 | 22 | 6960×2600×1630 |
| 3YK1860 | 1800×6000 | 3 | 10.8 | 5-80 | 400 | 50-360 | 8.6 | 22 | 7100×2680×1710 |
| 4YK1860 | 1800×6000 | 4 | 10.8 | 5-80 | 400 | 50-390 | 9.2 | 30 | 7242×2680×2046 |
| 2YK2160 | 2100×6000 | 2 | 12.6 | 5-100 | 400 | 100-400 | 8.8 | 30 | 7054×2990×1495 |
| 3YK2160 | 2100×6000 | 3 | 12.6 | 5-100 | 400 | 100-430 | 9.45 | 30 | 7220×2990×1952 |
| 4YK2160 | 2100×6000 | 4 | 12.6 | 5-100 | 400 | 120-460 | 10.9 | 45 | 7390×2990×2412 |
| 2YK2460 | 2400×6000 | 2 | 14.4 | 5-100 | 400 | 150-500 | 9.63 | 37 | 7054×3280×1495 |
| 3YK2460 | 2400×6000 | 3 | 14.4 | 5-100 | 400 | 150-550 | 11.5 | 45 | 7220×3280×1952 |
| 4YK2460 | 2400×6000 | 4 | 14.4 | 5-100 | 400 | 180-600 | 12.78 | 55 | 7390×3280×2412 |
