box molding machine/ fingerless single facer
- Tianjin Port
- T/T
You May Like
-
packing machine/ fingerless single facer
-
Semiauto diecutting machine/ packing machine
-
Fully auto printing and slotting machine/ carton machine
-
Adsorption flute laminating machine/ corrugated machine
-
Cutting machine / corrugated cardboard production line
-
Cutting machine / corrugated cardboard production line
Product Details
| Packaging Material | Metal | Automatic Grade | Automatic | |
| Driven Type | Pneumatic | Place of Origin | Hebei, China | |
| Brand Name | XINGLONG | Model Number | SF320S-360S |
Product Description
Specifications
box molding machine/ fingerless single facer1.Quality alloy roller
2. High speed, adsorption
box molding machine/ fingerless single facer
Function and Features:
1.. Vacuum adsorption transmitting cardboard equipment, with wind control.
2.Cardan drive, fission structure with unattached drive box, transmission more stable, close style gear transmission oiliness lubricated, prolong the use life of gear.
3. The upper corrugating roller, pressure roller and glue roller adopt pneumatic control.
4. The axletree of corrugated roller and pressure roller adopts high temperature resistant lube.
5. Electric adjust the glue quantity that figure show or manual adjust the glue quantity.
6. The upper-lower corrugating roller are made of 48CrMo high quality alloy steel, after heat-treatment. The rigidity is HRC58-60°,the surface are whetted and plating chrome.
Main Technology Parameter
Design Speed | 40-180m/min |
Working Speed | 40-150m/min |
Expiry Width | 1400mm-2200mm(1400mm,1600mm,1800mm,2000mm,2200mm) |
Power | About 27KW |
Diameter of corrugated roller | 215mm-360mm215mm, 245mm, 268mm,280mm,320mm,360mm or users appointed |
Flute Type | A,B,C,E for your choice(or user specified) |
