Home > Products > Ceramic rod ,shaft > 99% Precision Long Pink Alumina Ceramic Tube
99% Precision Long Pink Alumina Ceramic Tube
- SHANGHAI
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Jiangsu, China | Type | Ceramic Plates | |
| Application | Industrial Ceramic | |||
| Model Number | Customizable | Brand Name | EB |
Product Description
Specifications
1.Material:99% Alumina2.Wear resistance
3.High mechanical strenght
4,Custom design
5,Eco-friendly
99% precision long Pink alumina ceramic tube
Feature
Pink Alumina ceramic tube has the advantages of super hardness,high wear-resisting,good corrosion resistance ,high temperature tolerance,precision process, high mechanical strength, good chemical stability,good smoothness, mechanical seal good, and so on.
Property
Items | Unit | 95%Al2O3 | 99.5%Al2O3 |
Density | g/cm3 | 3.7 | 3.9 |
Flexural Strength | MPa | 313 | 340 |
Compressive Strength | MPa | 3400 | 3600 |
Modulus of Elasticity | GPa | 350 | 380 |
Impact Resistance | MPa·m1/2 | 4 | 5.1 |
Weibull Modulus | m | 10 | 10 |
Vickers Hardness | HV0.5 | 1800 | 1900 |
Thermal Conductivity | W/mk | 24 | 27 |
Highest Application Temperature | °C | 1600 | 1750 |
Volume Resistivity at 20°C | Ω.cm20 | >1014 | >1014 |
Dielertric strength | KV/mm | 20 | 25 |
Thermal expansion | X10-6/K | 5.0-8.3 | 5.4-8.3 |
Forming methods includes
1,Drying pressing
2,Isostatic pressing
3,Hot pressing casting
Application
1.ceramic block has the advantage of Wearlessness,resistant acid-base and high intensity ceramic assembly apply to petroleum ,chemical and chemical industry.it has good Wearlesness, corrosion resistance parts apply to precision machine.
Remarks
Customized production is available, for more information, please do not hesitate to tell me.Dimension, Tolerance, Surface Roughness, Concentricity, Perpendicularity and other specification are upon your requirements.
