Home > Products > SMA connector > RG 174 316 SMA Solder Jack Bulkhead Connector for RF aplication
RG 174 316 SMA Solder Jack Bulkhead Connector for RF aplication
USD $0.1 - $0.9
/ Piece
100 Pieces(Min. Order)
- Hongkong
- Credit Card
You May Like
-
Reverse Polarity SMA Male Crimp Connector - RG58, RG141 & LMR-195
-
right angle sma rf double male coaxial connector
-
SMA Plug Connector Crimp LMR300 to sma male to sma male
-
Female Gender and PCB Application sma female connector
-
SMA,manufacturer Type and Female Gender 20mm R/A pcb mount sma micro-strip rf connector
-
RF application sma female right angle pcb rf connector
Product Details
| Place of Origin | Guangdong, China | Brand Name | SH-Link | |
| Model Number | RPSMA-JY0.9-M-1 | Type | SMA | |
| Application | RF | Gender | Male |
Product Description
| Temperature range | -55—+155℃(PE Cable -40—+85℃) | ||
| Vibration | 98m/S²(10-2000Hz)10g | ||
| Impedance | 50Ω | ||
| Frequency range | DC-12.4GHz(Semi-Rigled Cable DC-18GHz) | ||
| Working voltage | 335V r.m.s at sea level | ||
| Withstanding voltage | 1000V r.m.s at sea level | ||
| Contact resistance | |||
| Center contact | ≤3mΩ | ||
| Outer contact | ≤2.5mΩ | ||
| Insulation resistance | ≥5000MΩ | ||
| Center conductor retention force | ≥0.28N | ||
| Coupling nut retention force | ≥180N | ||
| Insertion loss | ≤0.15dB/6GHz | ||
| Voltage Standing Wave Ratio | |||
| Straight | ≤1.10+0.02f | ||
| ≤1.07+0.018f | |||
| Right angle | ≤1.20+0.03f | ||
| ≤1.17+0.02f | |||
| Durability(mating) | ≥500(Cycles) | ||
