Home > Products > FME connector > FME digital inverter generator ,FME connectors,FME male to crc 9 pigtail cable
FME digital inverter generator ,FME connectors,FME male to crc 9 pigtail cable
US$ 0.1 - 1
/ Piece
1 Piece(Min. Order)
- Hongkong
- Credit Card
You May Like
-
RF coaxial female MCX connector for flexible cable
-
mcx connector gold plating for flexible cable,gsm repeater
-
rf coaxial audio jack MCX connector
-
right angle male MCX connector use in telecommunication towers
-
MCX Jack Female Right Angle PCB Coaxial Connector 50 ohms
-
RF Coaxial connector Male Right Angle MCX Connector
Product Details
| Place of Origin | Guangdong, China | Brand Name | SH-Link | |
| Model Number | FME-C-J1.5-3 | Type | Other, FME | |
| Application | RF | Gender | Male |
Product Description
Specifications
1.Type:FME
2.Male,crimp rf connector for rg174/316,50 Ohm
3.Pin:brass/gold plated
4.Good price,reliable quality
The thread of type FME product is M8X0.75. FME also have another name called SAP connector. They are used in the signal transmission with RF cable for all kind of electronic instruments, Mobile communications, and antenna systems at the frequency of 3GHz. They are in simple structure and reliable connection.
MAJOR TECHNICAL CHARACTERISTICS
| Temperature Range | -55~ +155°C (PE Cable -40~ +85°C) |
| Insertin loss | <=0.20dB/6GHz |
| Impedance | 50Ω |
| Frequency range | DC~3GHz |
| Working Voltage | 500V r.m.s at sea level |
| Withstanding voltage | 1000V r.m.s at sea level |
| Contact resistance | Center contact<=10m Ω Coter contact<=5m Ω |
| Insulation resistance | >=5000MΩ |
| Center conductor retentin force | >=0.57N |
| Voltage Standing Wave Ratio | Straight <=1.20 Right Angle <=1.25 |
| Durability(mating) | >=500 times (cycles) |
MATERIAL & PLATING
| Body | brass | nickel plated |
| pin contact | brass | gold plated |
| socket contact | beryllium or tin bronze | gold plated |
| insulator | PTFE | |
| crimp ferrule | copper alloy | nickel or gold plated |
