Home > Products > Steel bar straightening machine > GCr9 bearing steel bar rod two rollers straightening machine
GCr9 bearing steel bar rod two rollers straightening machine
Negotiable
/ Set
1 Set(Min. Order)
- Qingdao seaport
- T/T
You May Like
-
China yantai haige straightening machine for steel round bar
-
China JY60 two-rollers straightening machine for steel bar
-
China JY40Z cheap two rollers vertical straightening machine for round bars
-
China JY130A cheap two rollers vertical straightening machine for round bars
-
China JY100Z cheap two rollers vertical straightening machine for round bars
-
JY80A-frame type two-rolls metal round steel bar straightening machine
Product Details
| Condition | New | Type | Other, metal straightening machinery | |
| Use | Bar | Place of Origin | Shandong, China | |
| Brand Name | Haige | Model Number | JY8130A | |
| Voltage | 380V/440V | Power(W) | 200KW | |
| Certification | ISO9001 | Warranty | 1 year | |
| After-sales Service Provided | Overseas service center available |
Product Description
Specifications
GCr9 bearing steel bar rod two rollers straightening machine1. high speed
2. high precision
GCr9 bearing steel bar rod two rollers straightening machine
| Main Technical Parameters | |||||
| Specification | JY130A | ||||
| Requirements | Diameter Range(mm) | 35≤dia≤130 | |||
| Length(mm) | ≥3000 | ||||
| Surface Hardness | ≤HB380(≤HRC42) | ||||
| Yield Strength(Mpa) | σb≤450 | ||||
| Straightness(mm/m) | ≤3 | ||||
| Diameter Tolerance | ≤IT10 | ||||
| Circular Degree | dia≤50 | ≤50% of diameter tolerance | |||
| 50<dia≤80 | ≤65% of diameter tolerance | ||||
| dia>80 | ≤70% of diameter tolerance | ||||
| Surface Roughness(Ra) | 3.2μm~6.3μm | ||||
| After Straightening | Straightness(mm/m) | ≤0.40 | |||
| Surface Roughness(Ra) | ≤0.8μm | ||||
| Diameter Tolerance | ≤IT8 | ||||
| Straightening speed (m/min) | 2~10 | ||||
| Total Capacity(kw) | 200 | ||||
| Outline Dimension(m) | 11 X 3.4 X 4.3 | ||||
