Home > Products > Plastic machinery > MG-HR Automatic Heat Resistance Stretch Blow Moulding Machine
MG-HR Automatic Heat Resistance Stretch Blow Moulding Machine
- SHANGHAI QINGDAO GUANGZHOU
- T/T
You May Like
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | PET | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | Yes | Place of Origin | Anhui, China | |
| Brand Name | koco | Model Number | MG-HR | |
| Voltage | 380V/3PH/50Hz or special order | Power(W) | 28KW | |
| Dimension(L*W*H) | 280x180x220cm | Weight | 4.5 Ton |
Product Description
Features
MG-HR series is specially designed to produce PET bottle with high heat resistance for
hot filling package such as juice and RTD tea. It adopts multiple blowing to reduce the
residual stress. as a result, shaped bottle has slight shrinkage during hot filling. PET
bottles can stand temperature over 100°C depending on the type of PET
material with different crystallization rate.
General Information | MG-HR1500 | MG-HR2500 | MG-HR3500 |
Clamping Force | 30T | 40T | 50T |
Clamping Stroke | 150mm | 150mm | 150mm |
Max. Stretching Stroke | 370mm | 370mm | 370mm |
Bottom Moving Stroke | 70mm | 70mm | 70mm |
Number of Cavities | 2 Cavity | 4 Cavity | 6 Cavity |
Theoretical Output | 1000BPH | 2000BPH | 3500BPH |
Max. Mould Thickness | 300mm | 300mm | 300mm |
Space Between Tie Bars | 400x380mm | 640x380mm | 880x700mm |
Electrical System | |||
Voltage Standard | 380V/3PH/50Hz or special order | ||
Number of Heating Zone | 2 Sections | 4 Sections | 6 Sections |
Total Power(Full Loaded) | 28KW | 60KW | 70KW |
Container | |||
Max. Container Volume | 2.5L | 2.5L | 2.5L |
Neck Diameter Range | 32mm | 32mm | 32mm |
Max. Container Diameter | 35-100mm | 35-100mm | 35-100mm |
Max. Container Height | 400mm | 400mm |
|
Auxiliary System | |||
Low Air compressor | 8-10Bar | 8-10Bar | 8-10Bar |
High Air compressor | 30Bar | 30Bar | 30Bar |
Air Dryer | 3.0/30 | 3.0/30 | 3.0/30 |
Dimension & Weight (LxWxH) | |||
Blow molding machine | 280x180x220cm | 320x250x230cm | 550x210x230cm |
Pre-heater | 150x120x250cm | 150x120x250cm | 230x200x230cm |
Net Weight | 4.5 Ton | 8 Ton | 10 Ton |
