Air cooled diesel water pump KDP20

FOB Price

USD $215 - $250 / Set

10 Sets(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1.Max.lift(m) 15
2.Max.suction lift(m) 8
3.Easy maintance
4.Full frame structure and bilobed wheel design

Detailed Product Description

WUXI KAIAO POWER MACHINERY CO., LTD



Diesel Engine Water Pump
Model	KDP20
Diameter(mm) (inch)	50(2" )
Max. flow(m3/h)	22
Max. lift(m)	15
Max. suction lift(m)	8
Rotational speed(rpm)	3600
Self-priming time(s/4m)	80
Engine model	KA170F
Engine type	Single-cylinder, vertical, four-stroke,air cooled
*Borestroke(mm)**	*7055**
Displacement (L)	0.211
Power (kW)	2.8/3600
Fuel consumption rate(g.kW/h)	288
Compression ratio	20
Lubrication system	Pressure splash Type
Engine starting system	Recoil starter
Fuel oil model	Summer:0#,Winter:-10#
Lube oil model	SAE10W-30 (above CD grade)
Lube oil capacity (L)	0.75
Fuel tank capacity (L)	2.5
*Dimension (LWH)(mm)*	*525435555*
Net weight(kg)	35
Gross weight(kg)	38
